LCD Monitor User Manual E2495SD /E2495SH LED Backlight www.aoc.com ©2012 AOC.All Rights Reserved.
Safety........................................................................................................................................................................ 4 National Conventions ......................................................................................................................................... 4 Power ................................................................................................................................................................
WEEE Declaration for India ............................................................................................................................. 47 EPA Energy Star .............................................................................................................................................. 48 EPEAT Declaration .......................................................................................................................................... 49 Service ..........................
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature.
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. Please disconnect the power cord before cleaning the product.
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.
Setup Contents in Box Monitor CD Manual Power Cable Stand Analog Cable DVI Cable Base wire holder HDMI Cable Audio Cable Not all signal cables (Analog , Audio, DVI and HDMI cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
Setup Stand & Base Please setup or remove the base following the steps as below.
Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from -5° to 22 °. NOTE: Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
Connecting the Monitor Cable Connections In Back of Monitor and Computer: E2495SD E2495SH E2495SD 1. Power 2. DVI (Optional) 3. Analog (DB-15 VGA cable) E2495SH 1. 2. 3. 4. Power HDMI (Optional) Analog (DB-15 VGA cable) Line in (Optional) To protect equipment, always turn off the PC and LCD monitor before connecting. 1 Connect the power cable to the AC port on the back of the monitor.
Wall Mounting Preparing to Install An Optional Wall Mounting Arm. This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure. Follow these steps: 1 Remove the base. 2 Follow the manufacturer's instructions to assemble the wall mounting arm. 3 Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the monitor. 4 Insert the 4 screws into the holes and tighten.
Adjusting Setting Optimal Resolution Windows Vista For Windows Vista: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Personalization.
5 Click Display Settings. 6 Set the resolution SLIDE-BAR to Optimal preset resolution.
Windows XP For Windows XP: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Click Appearance and Themes. 5 Double click DISPLAY.
6 Click SETTINGS. 7 Set the resolution SLIDE-BAR to Optimal preset resolution. Windows ME/2000 For Windows ME/2000: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Double click DISPLAY. 5 Click SETTINGS. 6 Set the resolution SLIDE-BAR to Optimal preset resolution. .
Hotkeys E2495SD 1 Source/Auto/Exit 2 ECO(DCR)/- 3 4:3 or Wide /+ 4 Menu/Enter 5 Power E2495SH 1 Source/Auto/Exit 2 ECO(DCR)/- 3 Volume /+ 4 Menu/Enter 5 Power Power Press the Power button to turn on/off the monitor. Eco (DCR/I-Care)/Press the Eco key continuously to select the Eco mode of brightness and DCR/I-Care on when there is no OSD. ( Eco mode hot key may not be available in all models).
OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press - or + to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. press - or + to navigate through the sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it. 3) Press - or + to change the settings of the selected function. Press AUTO to exit.
Luminance 1 Press MENU to display menu. 2 Press - or + to select (Luminance), and press MENU to enter. 3 Press - or + to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 press AUTO to exit.
Image Setup 1 Press MENU to display menu. 2 Press - or + to select (Image Setup), and press MENU to enter. 3 Press - or + to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 Press AUTO to exit. Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise Phase 0-100 Adjust Picture Phase to reduce Horizontal-Line noise Sharpness 0-100 Adjust picture sharpness H.Position 0-100 Adjust the horizontal position of the picture V.
Color Setup 1 Press MENU to display menu. 2 Press - or + to select (Color Setup), and press MENU to enter. 3 Press - or + to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 Press AUTO to exit. Color setup.
Picture Boost 1 Press MENU to display menu. 2 Press - or + to select (Picture Boost), and press MENU to enter. 3 Press - or + to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 Press AUTO to exit. Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast H. position 0-100 Adjust Frame horizontal Position V.
OSD Setup 1 Press MENU to display menu. 2Press - or + to select (OSD Setup), and press MENU to enter. 3 Press - or + to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 Press AUTO to exit. Adjust the horizontal position of H.Position 0-100 V.
Extra 1 Press MENU to display menu. 2 Press - or + to select 3 Press - or + (Extra), and press MENU to enter. to select submenu, and press MENU to enter. 4 Press - or + to adjust. 5 Press AUTO to exit. Input Select Auto / Analog / DVI / HDMI Select input signal source. Auto Config yes or no Auto adjust the picture to default. Off timer 0-24hrs Select DC off time. Image Ratio wide or 4:3 Select wide or 4:3 format for display. DDC-CI yes or no Turn ON/OFF DDC-CI Support.
Exit 1 Press MENU to display menu. 2 Press - or + to select (Exit), and press MENU to enter. 3 Press AUTO to exit.
Driver Monitor Driver Windows 7 1.Start Windows® 7 2.Click on the 'Start' button and then click on 'Control Panel'. 3. Click on the 'Display' icon.
4.Ckick on the “Change display settings” button. 5.Click the “Advanced Settings” button. 6.Click the “Monitor” tab and then click the “Properties” button.
7.Click the “Driver” tab. 8. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “and then click the "Browse my computer for driver software" button. 9. Select "Let me pick from a list of device drivers on my computer".
10. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 11. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 12. Select your monitor model and click the “Next” button. The files will be copied from the CD to your hard disk drive. 13. Close all open windows and remove the CD. 14. Restart the system.
Windows Vista 1. Click "Start " and "Control Panel". Then, double-click on "Appearance and Personalization". 2. Click "Personalization" and then "Display Settings". 3. Click "Advanced Settings...".
4. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is. If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue". 5. Click "Update Driver..." in the "Driver" tab. 6. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer". 7. Click on the 'Have disk...
Windows XP 1. Start Windows® XP 2. Click on the 'Start' button and then click on 'Control Panel'. 3. Select and click on the category ‘Appearance and Themes’ 4. Click on the 'Display' Item.
5. Select the 'Settings' tab then click on the 'Advanced' button. 6. Select 'Monitor' tab - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active, click on 'Properties' button. Please follow the steps below. 7. Click on the 'Driver' tab and then click on 'Update Driver...' button.
8. Select the 'Install from a list or specific location [advanced]' radio button and then click on the 'Next' button. 9. Select the 'Don't Search. I will choose the driver to install' radio button. Then click on the 'Next' button. 10. Click on the 'Have disk...' button, then click on the 'Browse...' button and then select the appropriate drive F: (CD-ROM Drive). 11. Click on the 'Open' button, then click the 'OK' button. 12. Select your monitor model and click on the 'Next' button.
Windows 2000 1. Start Windows® 2000 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...'. 5. Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active. Click on 'Properties' button. Please follow the steps given below. 6.
i-Menu Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide.
e-Saver Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). Please click on "driver/e-Saver/setup.exe" to start installing the e-Saver software, follow the install wizard to complete software installation.
Screen+ Welcome to "Screen+" software by AOC, Screen+ software is a desktop screen splitting tool, it splits the desktop into different panes, each pane displays a different window. You only need to drag the window to a corresponding pane, when you want to access it. It supports multiple monitor display to make your task easier. Please follow the installation software to install it.
Troubleshoot Problem & Question Possible Solutions Make sure the power button is ON and the Power Cord is properly connected Power LED Is Not ON to a grounded power outlet and to the monitor. Is the power cord connected properly? Check the power cord connection and power supply. Is the cable connected correctly? (Connected using the D-sub cable) Check the DB-15 cable connection. (Connected using the DVI cable) Check the DVI cable connection. * DVI input is not available on every model.
The Computer Power Switch should be in the ON position. The Computer Video Card should be snugly fitted in its slot. Make sure the monitor's video cable is properly connected to the computer. Monitor Is Stuck In Active Inspect the monitor's video cable and make sure no pin is bent. Off-Mode" Make sure your computer is operational by hitting the CAPS LOCK key on the keyboard while observing the CAPS LOCK LED. The LED should either turn ON or OFF after hitting the CAPS LOCK key.
Specification General Specification Panel Resolution Model name E2495SD/ E2495SH Driving system TFT Color LCD Viewable Image Size 60.97 cm diagonal Pixel pitch 0. 27675 mm(H) x 0. 27675 mm(V) Video R, G, B Analog lnterface & Digital Interface & HDMI lnterface Separate Sync H/V TTL Display Color 16.7M Colors Dot Clock 170 MHz Horizontal scan range 30 kHz - 83 kHz Horizontal scan Size(Maximum) 531.36 mm Vertical scan range 50 Hz - 76 Hz Vertical scan Size(Maximum) 298.
Preset Display Mode STAND RESOLUTION Horizontal (kHz) Vertical(Hz) 640×480@60Hz 31.469 59.94 640×480@72Hz 37.861 72.809 640×480@75Hz 37.5 75 800×600@56Hz 35.156 56.25 800×600@60Hz 37.879 60.317 800×600@72Hz 48.077 72.188 800×600@75Hz 46.875 75 1024×768@60Hz 48.363 60.004 1024×768@70Hz 56.476 70.069 1024×768@75Hz 60.023 75.029 SXGA 1280x1024@60Hz 63.981 60.02 SXGA 1280x1024@75Hz 79.976 75.025 WXGA 1440x900@60Hz 55.935 59.887 WSXGA+ 1680x1050@60Hz 65.29 59.
Pin Assignments Pin Number 15-Pin Side of the Signal Cable 1 Video-Red 2 Video-Green 3 Video-Blue s N.C. 5 Detect Cable 6 GND-R 7 GND-G 8 GND-B 9 +5V 10 Ground 11 N.C.
Pin No. Signal Name Pin No. Signal Name Pin Signal Name No. 1 TMDS Data 2+ 9 TMDS Data 0 17 DDC/CEC Ground 2 TMDS Data 2 Shield 10 TMDS Clock + 18 +5V Power 3 TMDS Data 2 11 TMDS Clock Shield 19 Hot Plug Detect 4 TMDS Data 1+ 12 TMDS Clock 5 TMDS Data 1Shield 13 CEC 6 TMDS Data 1 14 Reserved (N.C.
Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
WEEE Declaration Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment .
EPA Energy Star ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) BV and Envision Peripherals, Inc. have determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
EPEAT Declaration EPEAT is a system to help purchasers in the public and private sectors evaluate, compare and select desktop computers, notebooks and monitors based on their environmental attributes. EPEAT also provides a clear and consistent set of performance criteria for the design of products, and provides an opportunity for manufacturers to secure market recognition for efforts to reduce the environmental impact of its products. AOC believes in protecting the environment.
Service EU WARRANTY FOR AOC MONITORS LIMITED THREE-YEAR WARRANTY* For AOC LCD Monitors sold within Europe, AOC International (Europe) B.V. warrants this product to be free from defects in material and workmanship for a period of Three (3) years after the original date of consumer purchase. During this period, AOC International (Europe) B.V. will, at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below.
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO A PERIOD OF THREE (3) YEARS FOR PARTS AND LABOR FROM THE ORIGINAL DATE OF CONSUMER PURCHASE. NO WARRANTIES (EITHER EXPRESSED OR IMPLIED) APPLY AFTER THIS PERIOD. AOC INTERNATIONAL (EUROPE) B.V. OBLIGATIONS AND YOUR REMEDIES HEREUNDER ARE SOLELY AND EXCULSIVELY AS STATED HERE. AOC INTERNATIONAL (EUROPE) B.V.
Warranty Statement for North & South America (excluding Brazil) WARRANTY STATEMENT for AOC Color Monitors Including those Sold within North America as Specified Envision Peripherals, Inc. warrants this product to be free from defects in material and workmanship for a period of three (3) years for parts & labor and one (1) year for CRT Tube or LCD Panel after the original date of consumer purchase. During this period, EPI ( EPI is the abbreviation of Envision Peripherals, Inc.
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO A PERIOD OF THREE (3) YEARS FOR PARTS AND LABOR AND ONE (1) YEAR FOR CRT TUBE OR LCD PANEL FROM THE ORIGINAL DATE OF CONSUMER PURCHASE. NO WARRANTIES (EITHER EXPRESSED OR IMPLIED) APPLY AFTER THIS PERIOD. IN THE UNITED STATES OF AMERICA, SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
TCO DOCUMENT (FOR TCO CERTIFIED MODELS) 54
Only for AOC branded monitors sold within the continental United States. All AOC branded monitors are now covered by the EASE Program. If your monitor malfunctions at any time during the first three months, AOC will provide a replacement monitor within 72 hours after you are approved for our program. If your monitor qualifies for the EASE program, AOC will pay for freight both ways. Step 1: Phone our TECH Department at 888.662.9888 Step 2: Fill out and return EASE registration forms by mail or fax.
