Specification
General Specification
Panel
Model
name AG271QX
Driving system
TFT Color LCD
Viewable Image Size
68.5 cm diagonal
Pixel pitch
0. 2331mm(H) x 0.2331mm(V)
Video
R, G, B Analog lnterface& DVI interface& HDMI lnterface& DP
Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Others
Horizontal scan range
30k - 99kHz(D-SUB/ DVI-Dual-Link/ MHL)
30k-160kHz(HDMI1.4b)
30k-230kHz(HDMI2.0/DP)
Horizontal scan Size(Maximum)
596.74mm
Vertical
scan range
23-76Hz(MHL)
50-76Hz(D-SUB/DVI-Dual-Link)
30-146Hz(HDMI/DP)
Vertical Scan Size(Maximum)
335.66mm
Optimal preset resolution
1920x1080@60Hz(D-SUB\MHL)
2560x1440@60Hz(DVI-Dual-Link\HDMI1.4b\DP)
2560x1440@144Hz(DP/HDMI2.0)
Plug & Play
VESA DDC2B/CI
Input Connector
VGA /DVI Dual-Link /HDMI /MHL/DP/Audio input/USB
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Output Connector
Earphone、Microphone out
Power Source
20Vdc, 6A
Power Consumption
Typical(Brightness = 90,Contrast = 50)
47
W
(brightness = 100, contrast =100)
96
W
Power saving
≤
0.5W
Off timer
0~24 hrs
Speakers
3W x 2
Physical
Characteristics
Connector Type
VGA\DVI Dual-Link\HDMI\MHL\DP\Audio input \Earphone
out\Microphone in\Microphone out\USB3.0
Signal Cable Type
Detachable
Dimensions & Weight:
Height(with Base)
433~563mm
Width
623mm
Depth
218mm
Weight(Monitor only)
6.8Kg
