93FW+ TABLE OF CONTENTS FOR YOUR SAFETY -------------------------------------------------- 1 SAFETY PRECAUTIONS -------------------------------------- 2 SPECIAL NOTES ON LCD MONITORS ------------------- 3 BEFORE YOU OPERATE THE MONITOR --------------------FEATURES -------------------------------------------------------PACKING LIST --------------------------------------------------INSTALLATION INSTRUCTIONS --------------------------CONTROLS AND CONNECTORS -------------------------ADJUSTING THE VIEWING ANGLE
Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
PRECAUTIONS z Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. z Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES • Due to the nature of the fluorescent light, the screen may flicker during • • • initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. You may find slightly uneven brightness on the screen depending on the desktop pattern you use. The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.
INSTALLATION INSTRUCTIONS SWIVEL BASE Install Figure 1 Remove Installing and Removing the Swivel Base POWER CORD Power Source: 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an External universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.) 3.
CONTROLS AND CONNECTORS VIDEO CABLE Connecting the D-Sub Cable: Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer’s D-Sub port. Connecting the Power Cord: Plug the AC-power cord into the External Adapter. Then plug the DC-jack power cable into DC-IN Inlet. Connecting the DVI Cable: Connect one end of the 24-pin DVI cable to the back of the monitor and connect the other end to the computer’s DVI port.
ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle. • You are able to adjust the monitor’s angle from -5° to 20°. Figure 3 NOTES • Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. • The power cord should be connected. • Connect the video cable from the monitor to the video card. • Press the power button to turn on the monitor position. The power indicator will light up.
FRONT PANEL CONTROL • Power Button: Press this button to switch ON/OFF of monitor’s power. • MENU / ENTER : Activate OSD menu when OSD is OFF or activate/de-activate adjustment function when OSD is ON or Exit OSD menu when in Brightness/ Contrast Adjust OSD status. • Luminance : Adjust contrast and brightness or function adjust. *Only adjustable at “STD” mode (see Brightness Preset below) • Brightness Preset: Switch between “STD”, “OFFICE” & “VIVID”. • Auto Adjust button / Exit: 1. 2.
HOW TO ADJUST A SETTING 1. Press the MENU-button to activate the OSD window. 2. Press or to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. If the function selected has a sub-menu, press or again to navigate through the sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it. 3. Press or to change the settings of the selected function. 4. To exit and save, select the exit function.
ADJUSTING THE PICTURE The descriptions for function control LEDS Main Sub Main Sub Menu Menu Menu Menu Item Item Icon Icon Description Contrast Contrast from Digital-register. Brightness Backlight Adjustment Focus Adjust Picture Phase to reduce Horizontal-Line noise Clock Adjust picture Clock Vertical-Line noise. H. Position Adjust the horizontal position of the picture. V. Position Adjust the verticalposition of the picture. Luminance Image Setup Image Position Color Temp.
Main Main Sub Menu Menu Menu Item Item Icon Sub Menu Icon Description H. Position Adjust the horizontal position of the OSD. V. Position Adjust the verticalposition of the OSD. OSD Setup OSD Timeout Adjust the OSD timeout. Language Language N/A Select the language you like. Information Information N/A Show the resolution, H/V frequency and input port of current input timing. Yes N/A Clear each old status of Autoconfiguration . No N/A Do not execute reset, return to main menu.
PLUG AND PLAY Plug & Play DDC 2B Feature This monitor is equipped with VESA DDC 2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC 2B is a bidirectional data channel based on the I²C protocol. The host can request EDID information over the DDC 2B channel.
TECHNICAL SUPPORT (FAQ) Problem & Question Power LED is not on Possible Solution *Check if the Power Switch is in the ON position *Power Cord should be connected No Plug & Play *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the LCD Monitor Drivers are installed Picture is fuzzy *Adjust the Contrast and Brightness Controls.
ERROR MESSAGE & POSSIBLE SOLUTION CABLE NOT CONNECTED : 1. Check that the signal-cable is properly connected , If the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode ,set the computer to display mode given in the following table.(see page 18) 14 Downloaded from ManualMonitor.
HOW TO INSTALL THE DRIVER-DISK (INF & ICM FILE) FOR FIRST TIME INSTALL : Your system may not recognize your flat-panel monitor,and as a result, you may need to complete the following steps for optimum performance of your monitor. 1. 2. 3. Check this LCD MONITOR is properly connected to your computer.
APPENDIX SPECIFICATIONS Driving system TFT Color LCD LCD Panel Size 48cm(19") Pixel pitch 0.285mm( H ) × 0.285mm( V ) R,G,B Analog Interface Video Digital Interface Input Separate Sync. H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 55-75Hz Display Colors 16.2M Colors Dot Clock 135MHz Max. Resolution 1440 × 900 @60Hz Plug & Play VESA DDC 2BTM ® EPA ENERGY STAR ON Mode ≤36W OFF Mode ≤1W Input Connector 15-pin D-Sub DVI 24pin Input Video Signal Analog:0.
• • • • • • • • • • • • • • • • • • • • • Switch External Controls: Functions Power Consumption ( Maximum ) Auto Adjust Key Brightness Preset Luminance Power Button MENU Contrast Brightness Focus Clock H. Position V. Position (Warm)Color (Cool)Color sRGB RGB Color temperature Input select OSD Setup Language Information Reset Exit 36 Watts Regulatory Compliance cULus, CE, MPR II,TCO’99 17 Downloaded from ManualMonitor.
Preset Display Modes STANDARD RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY Dos-mode 720 × 400 31.47kHz 70.0Hz VGA SVGA XGA SXGA WXGA+ 640 × 480 31.47kHz 60.0Hz 640 × 480 37.50kHz 75.0Hz 800 × 600 37.879kHz 60.0Hz 800 × 600 46.875kHz 75.0Hz 1024 × 768 48.363kHz 60.0Hz 1024 × 768 56.476kHz 70.0Hz 1024 × 768 60.021kHz 75.0Hz 1280 × 1024 64.000kHz 60.0Hz 1280 × 1024 80.000kHz 75.0Hz 1440 × 900 55.935kHz 18 Downloaded from ManualMonitor.com Manuals 59.
CONNECTOR PIN ASSIGNMENT 1 5 6 10 11 15 15 - Pin Color Display Signal Cable PIN NO. 1. 2. 3. 4. 5. 6. 7. 8. DESCRIPTION PIN NO. DESCRIPTION 9. 10. 11. 12. 13. 14. 15. +5V Detect Cable Ground DDC-Serial Data H-Sync V-Sync DDC-Serial Clock Red Green Blue Ground Ground R-Ground G-Ground B-Ground 24 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. 1. 2. 3. TMDS Data 2TMDS Data 2+ TMDS Data 2/4 Shield TMDS Data 4TMDS Data 4+ DDC Clock 13. 14. 15. 4. 5. 6. 7. 8. 9. 10. 11. 12. 16.
