Installation Guide

PARTS LIST
PERFECTION IS OUR TRADITION™
pg. 1
1. Shower Head
2. Diverter
3. Body Jets
4. Mixer
5. Hand Shower
1
2
4
3
3
5
1
6
7
8
9
10
2
3
4
5
11
12
13
18
19
20
17
16
15
14
Component no.
Component
Material
1
head shower
ABS
2
arm bar
brass
3
flange
brass
4
body panel
Aluminum
5
one way joint
ABS
6
body jets
ABS
7
knob
zinc
8
knob plate
brass
9
function cartridge
ABS
10
handle
zinc
11
handle plate cover
brass
12
catridge cap
ABS
13
thermostatic cartridge
ABS
14
clip
s/s
15
faucet
brass
16
hand shower
ABS
17
hand shower holder
ABS
18
braided hose
s/s
19
flexible hose
s/s
