Specifications

25
SURROUND MODES (MAIN) continued
•
Mono
•
Mono-Academy
•
All-Channel Mono
•
Individual Speaker Levels Memorized
for Each Mode
5.1/6.1 MODES
(MAIN)
•
Dolby
®
Digital 5.1
•
Dolby
®
Digital EX
™
•
DTS
®
5.1
•
DTS
®
ES Matrix
•
DTS
®
ES Discrete
•
DTS
®
2-Channel Stereo Downmix
(For Headphone, Zone 2, Zone 3, Record)
•
Dynamics Adjustment (Dolby
®
Digital and DTS
®
)
•
Dynamics Reset to Normal at Power Off
•
Individual Speaker Levels Memorized for
Each Mode
THX
®
MODES (MAIN)
•
THX
®
Cinema
•
THX
®
Ultra2
™
Cinema
•
THX
®
MusicMode
•
THX
®
Surround EX
™
•
THX
®
Games Mode
•
THX
®
ReEQ: On/Off
(can be applied even when THX
®
is turned Off)
BASS MANAGEMENT (MAIN)
•
Independent Cinema and Music Speaker
Configurations
(Assignable to Each Source)
•
Auto-LFE Option (For Cinema or Music
Configuration)
•
Dipole Setting for Surround/Rear
•
Center Channel EQ
•
Room Resonance Filter
•
THX
®
Boundary Gain Compensation
•
Super Subwoofer Setting (Subwoofer Operates
when Fronts are Set to Large)
•
Cinema and Movie Configurations each include:
– Independent Crossovers by Speaker Group
5-Hz Steps)
– Independent Crossover for Subwoofer
(5-Hz Steps)
– Subwoofer Variable Phase
– Subwoofer Polarity
– LFE Crossover Bypass
ZONE 2
•
(1) Stereo S/E Analog Audio Output
•
(1) Stereo True-Balanced
™
(XLR) Audio Output
•
Variable or Fixed Volume Level Setting
•
Adjustable Maximum Volume Setting
•
Bass, Treble, Balance Controls
•
(1) S-Video Output
•
(1) Composite Video Output
•
Simultaneous S-Video and Composite Outputs
•
Simulcast Video+Audio Sources
•
On-Screen Display (Bypassable)
•
On-Screen Setup Menu
ZONE 3
•
(1) Stereo S/E Analog Audio Output
•
Variable or Fixed Volume Level Setting
•
Adjustable Maximum Volume Setting
•
Bass, Treble, Balance Controls
•
(1) S-Video Output
•
(1) Composite Video Output
•
Simultaneous S-Video and Composite Outputs
•
Simulcast Video+Audio Sources
RECORD
•
Tape Record Out:
(1) Stereo S/E, (1) S-Video, (1) Composite
•
VCR Record Out:
(1) Stereo S/E, (1) S-Video, (1) Composite
•
(2) Coaxial Digital Record Outputs (Independent)
•
Analog-In to Digital-Out (Selectable 16-bit/
44 kHz, 16-bit/48 kHz, 24-bit/88 kHz,
24-bit/96 kHz)
•
Dithered Output for 16-bit Recording
CUSTOM INSTALLATION
•
(2) 50-mA Trigger Outputs
•
(1) 200-mA Trigger Output
•
(3) Powered IR Receivers
•
(2) IR Emitters
•
RS-232 Communication/Internet
Upgradeability
•
RS-232 Crestron
®
and AMX
™
Compatible
•
IEEE 1394 (Firewire
®
) Provision
•
Front-Panel Lockout Option
•
User Settings Save Function
•
Installer Settings Save Function
•
Setup Menu Lockout
•
Wake-Up/Shut-Off Timers (Main, Zone 2, Zone 3)
•
On/Off Skip Timers (Main, Zone 2, Zone 3)
•
Sleep Timers (Main, Zone 2, Zone 3)
UPGRADEABILITY
•
Hardware Upgradeable
•
Easy (and at no charge) Website Software
Upgradeability
ADDITIONAL
•
Universal Learning Back-Lit Remote Control
•
Power Failure / Overheating Text Warning
•
5-Year Warranty (1 Year on Remote Control)
