Specifications

WHY THE AVM 30 IS THE BEST-SELLING
PREAMPLIFIER/PROCESSOR IN ITS CLASS
(and above!)
•
Designed and built in North America by Sonic Frontiers
•
Component parts are carefully chosen for their ability to maintain
the lowest possible total harmonic distortion and noise
(THD + N)
•
Handcrafted circuit board layouts (not done by auto-routers) with
extensive use of groundplanes achieve exceptionally low noise,
low crosstalk, and protect against electrostatic discharge
•
4-layer motherboard with separate power- and groundplanes
•
6-layer DSP, A/D and D/A boards. A/D and D/A boards use
separate analog and digital planes, as well as separate power-
and groundplanes
•
All critical signal paths are surrounded by groundplanes,
a painstaking, dedicated design process
•
Large, conservatively rated toroidal-transformer-based linear power
supply minimizes radiation interference
– Two power transformers—total 120 VA
– Low-radiating, low-noise main toroidal transformer
•
Ten power supply regulation stages
•
Our own precision Digital Signal Processing design using one of
the most powerful DSP engines in the industry—the Freescale
™
Semiconductor DSP 56367 rated at 150 million instructions per
second
•
Individual low-jitter RS-485 line receivers on all digital inputs
•
Superior Digital-to-Analog/Analog-to-Digital conversion
– D/A uses AKM
®
AK4382 converters capable of up to 24-bit x
192 kHz resolution
– A/D uses AKM
®
AK5383 converters operating at up to
24-bit x 96 kHz resolution
•
Audiophile-grade operational amplifiers (Burr-Brown
™
OPA 2134's
and Motorola
®
MC33078’s)
•
Superior-quality (Crystal
®
CS3310) analog attenuator
(volume control)
•
Fully buffered audio and video inputs for minimum crosstalk
•
Highest-quality video-switching circuitry on completely independent
and isolated circuit boards
•
High-precision thru-hole passive components
•
Heavy-gauge non-resonant chassis
•
Headphone amplifier features a high-current/voltage design with
a dedicated fully discrete output stage
•
Massive mechanical shielding
Especially for the Purist
•
Analog-Direct available on all inputs (bypasses A/D’s, DSP and D/A’s)
•
Tone Bypass (removes Bass/Treble from the signal path)
•
Balanced 2-channel XLR Digital input (AES/EBU) provides the best
digital signal transmission possible
•
True-Balanced
™
2-channel Analog input for the best analog signal
transmission possible
•
True-Balanced
™
Analog outputs provide the best noise rejection
and purest analog signal transmission possible
•
For best possible video performance, on-screen displays can be
disabled, completely removing their character generators from the
video signal path
The AVM 30 incorporates the same user-friendly Operating System
as our Anthem
™
Statement D1. For the complete Operating Overview
see pages 7 to 13.
DESIGN OVERVIEW
•
(4) Independent Signal Paths (Main, Zone 2, Zone 3, Record)
INPUTS
•
Auto Digital/Analog Input Switching (For Every Source)
•
Built-In FM/AM Tuner with Stereo/High-Blend/Mono Setting
(Memorized to each FM Preset)
•
(7) Coaxial Digital Audio Inputs (Assignable to Multiple Digital Sources)
•
(3) Toslink Digital Audio Inputs (Assignable to Multiple Digital Sources)
•
(1) AES/EBU Digital Audio Input (Assignable to Multiple Digital Sources)
•
Bit Rate/Sample Rate Status Indicator (Displays PCM,
Dolby
®
Digital, DTS
®
)
•
(7) Stereo S/E Analog Audio Inputs (DSP or Direct)
•
(1) Stereo True-Balanced
™
(XLR) Analog Audio Input (DSP or Direct)
•
(1) Six-Channel S/E Audio Input (DSP or Direct)
•
Source EQ (Independent for Each Source)
•
(4) Component Video Inputs (Assignable to Multiple Sources)
•
HDTV Video Switching (All formats up to 1080p)
•
(7) S-Video Inputs (Assignable to Multiple Sources)
•
(7) Composite Video Inputs (Assignable to Multiple Sources)
MAIN
•
(10) True-Balanced
™
(XLR) Analog Audio Outputs
•
(10) S/E Analog Audio Outputs
•
Second Center Channel Output (Parallel–Balanced and S/E)
•
Second Subwoofer Output (Parallel–Balanced and S/E)
•
(1) Stereo Headphone Output
(Independent Volume/Bass/Treble/Balance Controls)
•
(2) Component Video Outputs
•
(1) S-Video Output
•
(1) Composite Video Output
•
Mode Presets by Source (Assignable for Each Source)
•
Simulcast Video+Audio Sources
•
Lip-Sync Delay (For Each Source in half-ms increments)
•
Main Sources – Copy to Other Paths
•
On-Screen Display (Bypassable)
•
On-Screen Setup Menu
•
Selectable Setup Menu Background Color
(Blue, Black, Magenta)
•
Adjustable Mute Level
•
Direct Remote Control Codes for Modes
6-CHANNEL ANALOG-DSP
(MAIN)
(DVD-Audio/SACD)
•
Selectable 44 kHz, 48 kHz, 88 kHz, 96 kHz
•
Bass Management
•
Time Alignment for Listener Position
•
Bass/Treble
•
Lip-Sync Delay
•
THX
®
, Dolby
®
Pro Logic IIx and DTS
®
Neo:6 Post Processing
•
Surrounds can be Rerouted to Rears (5.1 Output)
•
Surrounds can be Copied to Rears (7.1 Output)
•
2-Channel Stereo Downmix
(For Headphone, Zone 2, Zone 3, Record)
SURROUND MODES (MAIN)
•
AnthemLogic–Music
™
(No Center Channel)
•
AnthemLogic–Cinema
™
(Up to 7.1)
•
Dolby
®
Pro Logic IIx Music (with Adjustments)
•
Dolby
®
Pro Logic IIx Movie
•
Dolby
®
Pro Logic IIx Matrix
•
Dolby
®
Pro Logic IIx Game
•
Dolby
®
Pro Logic
•
DTS
®
Neo:6 Music (Center Image Adjustment)
•
DTS
®
Neo:6 Cinema
•
All-Channel Stereo (Up to 7.1)
24
