Specifications

Triggers
Programmable trigger outputs can turn components that have a trigger
input, on or off. Three triggers provide tremendous flexibility. Set Trigger 1 to
Main power-on, connect it to the trigger input of your amplifier, press the
D1’s Main power button—your amplifier will turn on and off in tandem.
Use triggers to automate as much as you like. Turn your entire system on
or off with one button. Used with timers, triggers offer you even more
versatility. For example, set timers and triggers so that at 7:00 a.m. Main
turns on to DVD and triggers-on your TV, Amplifier and DVD Player—
even turn lights on or off; and your five-year-old can watch a movie on
Saturday morning and leave you time to sleep in.
Two 12-volt triggers operate at 50 mA and the third at 200 mA. Unique
to the D1, this third, higher-current trigger saves hundreds of dollars on
a separate outboard trigger, which would otherwise be required to operate
motorized products such as video projection screens.
D1
13
Three Powered IR Inputs, Two IR Emitter Outputs
All three infrared inputs can be powered from the D1’s built-in 12-V
power
supply, eliminating the need for costly external power supplies
required to
power IR repeaters. As well, two rear-panel infrared emitter outputs make it
easy to remote control your source components (CD, DVD) from another room.
Setup that’s Intuitive, Easy, and also “Remembers”
Our intuitive setup menu is easy to navigate, and our “what-you-see-is-
what-you-get” (WYSIWYG) front-panel buttons and display readouts
make the D1 a snap to operate. You can even rename sources and paths
to make them easier for your whole family to use. For example, change
the “AUX” source to read “Game” so your kids can easily locate the
source input for their video games. Change the Zone 2 path to “Den” to
easily locate the zone you are operating.
Once completed, settings can be saved and even password-protected.
Two saved files are included: one for User and one for Installer. Now, if
you ever need to revert to your own or your installer’s settings, simply
restore the saved file.
Let’s say someone changed a setup menu setting, it’s Saturday night and now
you can’t watch a movie. What do you do? No need to wait (and pay!) for a
service technician, just restore the saved settings file … and press “Play”.
Protect Your System and Yourself!
Password-protectable maximum volume settings let you protect your
amplifier and speakers from damage that could result from overdriving.
Independent volume settings are provided for each Path. You can protect
against hearing injury from headphones by setting the maximum volume!
Since all audio signals pass through the volume control, its quality is of
tantamount importance. Digital volume controls can add noise and distortion,
diminishing the purity of sound. The D1 uses superior wide-range Crystal
®
CS3310 analog volume controls with extremely low noise and distortion—
even at the lowest listening levels—for smooth, natural sound.
AANNTTHHEEMM AAVVMM 3300 SSEETTUUPP MMEENNUU
1. SET TIME / TIMERS
2. SPEAKER CONFIGURATION
3. LISTENER POSITION
4. SPEAKER LVL CALIBRATION
5. SOURCE SETUP / PRESETS
6. ADJUST INPUT LEVELS
7. A-D / AUDIO-OUT FORMAT
8. VOLUMES / RENAME PATHS
9. TRIGGERS / IR / RS-232
10. DISPLAYS / TIMEOUT
11. SAVE / RESTORE SETTINGS
12. LOCKOUT / PASSWORDS
Universal Learning Remote Control
The D1 Remote Control operates Main, Zone 2, Zone 3 and Record
Paths. It can also be programmed to operate six other components, such
as Televisions, DVD Players, CD Players, Satellite Receivers, VCRs and
more—an extensive universal library of codes is included. It can also
learn almost any other command to a button location. It is even smart
enough to let you know when its batteries are running low—the back
light (which normally glows blue) will remain off, and the red LED will
flash as it turns off. Intuitive, logically laid out, and easy to use, our
remote control lets you spend less time “fiddling” and more time taking
command of all your components.
Communication
The D1 makes communicating over home local area networks (LAN) very
easy. It is compatible with Crestron
®
and AMX
™
(via RS-232 interface).
Software Updates
What if the operation of the D1 or AVM 30 is upgraded in the future? No
problem. Updating is as easy as 1-2-3. First, connect your computer to the
Internet. Second, go to our website at www.anthemAV.com for the AVM 30
or www.statement.anthemAV.com for the D1 and download the latest
version of the software. Third, connect your computer to the D1 or AVM 30
and upload the new software. It’s easy and takes only a few minutes to fully
update your D1 or AVM 30 with the latest operating system.
"Future Ready" – Hardware Upgrades
Although no audio/video component can claim to be absolutely future
proof, Anthem has a proven track record when it comes to offering
upgrades that keep our products at the leading edge. While upgrades of
emerging new technologies (HDMI, FireWire
®
, etc.) will come at a cost,
that cost will be little more than the increased price of the unit with the
new technology incorporated. That means you can enjoy the vastly superior
performance of your D1 or AVM 30 today, with confidence for tomorrow.
