Clocking
Word Clock Input
• 1 x Input @ 75 Ohms 3 Vpp on BNC 32 – 192 kHz
Atomic Clock Input
N/A
Word Clock Outputs
• 1 × Outputs @ 75 Ohms on BNC 32 –192kHz
Clocking System
• 4th Generation Acoustically Focused Clocking
• 64-bit DDS
• Oven Controlled Crystal Oscillator
Clock Stability
<+/-0.02 ppm, oven controlled at 64.5ºC/ 148.1ºF
Clock Aging
< 1 ppm per year
Clock Calibration
< +/-0.001 ppm
Sample Rates (kHz)
32, 44.1, 48, 88.2, 96, 176.4, 192
Other
Operating Temperature
0-50°C, 32-122°F
Weight
3.1 kg / 6.83 lbs (approx )
Dimensions (approx)
• Width: 483 mm / 19”
• Height: 44 mm / 1.7”
• Depth: 226 mm / 8.6”
Electrical specs
DC Universal input: 18V
Power Consumption: 25 Watts Max
