11. Technical Specications
Analog
Analog Inputs
• 4 x Mic / Line / Instrument on XLR combos on the front
• 8 x Mic / Line on XLR combos on the rear
Analog Inserts
• 2 x Inserts on TRS (inputs 1,2)
Analog Outputs
• 2 x DB25 (16 channels)
• 2 x Stereo Monitor out on TRS (4 channels, only 1 pair active at a time)
• 2 x Stereo Headphone outs on TRS (4 channels)
• 2 x ReAmp outs on TRS (2 channels)
D/A Monitor Converter
Dynamic Range: 129 dB
THD + N: -108 dB
A/D Converter
Dynamic Range: 124 dB
THD + N: -112 dB
D/A Converter
Dynamic Range: 120 dB
THD + N: -107 dB
Mic Preamp
Gain: 0,10 – 65 dB
THD + N: -108 dB
Digital
Digital Inputs
• 1 x ADAT (up to 8 channels)
• 1 x S/PDIF
Digital Outputs
• 1 x ADAT (up to 8 channels)
• 1 x S/PDIF
USB I/O
• 1 x USB 3.0 Hi-Speed; 32 – 192 kHz, 64 channels I/O, Type B
HDX
• 1 x HDX, 32 channels I/O
