SW-250 Snow Machine USER MANUAL English € Français € Deutsch € 2011 Antari Lighting and Effects Ltd.
ANTARI SW-250 SNOW MACHINE INTRODUCTION Thank you for choosing Antari SW-250 Snow Machine. Prior to use, it is suggested to read the instructions carefully and thoroughly. By following the instructions listed in this user manual, you can look forward to the best haze effect and the most reliable performance of your Antari SW-250 Snow Machine for years to come. ! Please follow these operation and safety instructions to ensure a long and safe life for your SW-250.
UNPACKING & INSPECTION Open the shipping carton and check that all equipment necessary to operate the machine have arrived intact. The shipping carton should contain the following items: 1. Snow machine with power cable 2. W-1 wireless transmitter 3. Fluid tank 4. Hanging bracket 5. Screw set and user manual Before beginning initial setup of your ANTARI SW-250 Snow Machine, make sure that there is no evident damage caused by transportation.
. Fill with ANTARI SL-5(A) snow fluid. Any other types of fluid can damage the unit. When filled, place cap back on liquid tank. 5. Plug the power cable into a grounded electrical outlet and switch the power switch at the rear of the machine for powering on. TRANSMITTER REGISTRATION After powering on, the LCD screen will show sequentially ƒAntari SW-250„ and then ƒWireless Setup…„. Press button ƒA„ on the transmitter(s) to register when see ƒWireless Setup…„ is on.
Down/Volume buttons (10 to 200 seconds). Timer Out To set the output volume under timer mode by pressing Up/Timer and Down/Volume buttons (1 to 100 %). Volume Out To set the output volume under continuous mode by pressing Up/Timer and Down/Volume buttons (1 to 100 %). DMX512 Add. To set the DMX channel under DMX control mode by pressing Up/Timer and Down/Volume buttons (1 to 512 channels).
output is decreased, bigger snow flakes will be produced. However, the snow output volume will not be affected. Note: When the machine senses no fluid in the fluid pipe, LCD screen will blink and show ƒNo Fluid„. Meanwhile, the machine is locked and not able to output for preventing machine from further ineffective work. Check immediately if the snow fluid in tank has been run out. To unlock the LCD screen, press Stop for 2 seconds and the machine will try to pump again the snow fluid.
different transmitters that are registered with the machine. The included transmitter has been registered with the machine before shipment. It can be directly operated without any start-up setting. Battery change on the transmitter If the range of the transmitter decreases, the battery is probably exhausted and must be replaced. For this purpose, take off the housing cover and remove the used battery. Insert a fresh 12 V battery, and refit the housing cover. SC-2 (Optional): 25 ft.
DMX CONTROL OPERATION SW-250 has on-board DMX control and the addressing is via LCD control panel. SW-250 uses 1 channel to control output on/off and volume. The channel has a value range from 0 to 255. The on/off function can also be programmed with a DMX controller or DMX control software used by lighting and effects operator. Channel A 11-255 = ON (1%-100%) 0-10 = OFF If the value of channel A is set between 0 to 10, the unit is off. While the value is set between 11 to 255, the unit is on.
SNOW FLUID Antari SL-5/SL-5(A) fluid was designed for the use with Antari snow machines. Antari SL-5(A) is a non-toxic solution that produces fast-dissipating snow. TECHNICAL SPECIFICATIONS Model SW-250 Power Supply 110~120V AC / 50~60Hz Power Consumption 220~240V AC / 50~60Hz 600W (Min Output) , 1290 W (Max Output) Output Volume 250ml / min Tank Capacity 5 liters Fluid Consumption Rate 4mins / liter Weight 12.
C08SW2501 36
