2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial Ethernet switch that
display the power status and network status. Each LED indicator has a different color and has
its own specific meaning, see below in Table 2.1.
LED Color Description
P1 Green
On Powerinput1is active
Off Powerinput1isinactive
P2 Green
On Powerinput2is active
Off Powerinput2isinactive
Fault Red
On Powerinput1or2is inactive
Off
Power input1 and 2 are both functional or no power,
inputs
Link/Active
LAN Port 1~5
Green
On Connected to network
Flashing Networking is active
Off Not connected to network
Du
plex/Collision
LAN Port 1~ 5
Orange
On Ethernet port full duplex
Flashing Collision of packets occurs
Off
Ethernet port half duplex or not connect to network
2.5 Ethernet Ports

RJ-45 Ports
RJ-45 Ports (Auto MDI/MDIX): The RJ-45 ports are auto-sensing for 10Base-T, 100Base-TX
devices connections. Auto MDI/MDIX means that the switch can connect to another switch or
workstation without changing the straight-through or crossover cabling. See the figures as below
for straight-through and crossover cabling schematics.
Table 2.1
LED Indicators of LNX-500A Series
