7. Technical Specification
Table 7.1has the technical specifications for Antaira’s LNX-500A series: 5-port industrial unmanaged
Ethernet switch with 5*10/100Tx.
Standard
IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
Protocol CSMA/CD
Transfer Rate
14,880pps for Ethernet port
148,800pps for fast Ethernet port
Transmission Distance Up to 100M (Fast Ethernet)
Transmission Speed Up to 100Mbps
RJ45 (Ethernet) Port
5*10/100Tx auto negotiation speed, full/half duplex
mode, and auto MDI/MDI-X connection
LED
Unit P1, P2, Fault Tx port:
Link/Active, Full Duplex/Collision
Over Current Protection Slow-blown fuse
Power Input
Redundant power DC12~48V with connective
1*6-Pin removable terminal block
Fault Output 1 relay output
Max Power Consumption 3 watts
Installation DIN-Rail mounting, wall mounting (optional)
Operating Temperature
Standard: -10
o
C to 70
o
C (14°to140° F)
EOT: -40
o
C to 75
o
C (-40°to167° F)
Operating Humidity 5% to 95% (Non-Condensing)
Storage Temperature -40
o
C to 85
o
C (-40°F ~ 185°F)
Case Dimension IP-30, 30mm (W) x 95mm (D) x 140mm (H)
EMI
FCC Class A
CE EN61000-4-2,3,4,5,6,8,11,12
CE EN61000-6-2
CE EN61000-6-4
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
