Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 1. Overview Antaira’s LNX-0501G-SFP industrial gigabit unmanaged Ethernet switch series are IP30 rated and DIN-Rail mountable. Each unit is designed with four gigabit Ethernet ports and one dual rate (100/1000) SFP slot, making it ideal for applications that demand high bandwidth and long distance communication.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 Case/Installation IP-30 protection Installation in pollution degree to environment DIN-Rail and wall mount design 1.2 Package Contents 1 - LNX-0501G-SFP (T): 5-port industrial gigabit unmanaged Ethernet switch, w/4*10/100/1000Tx, and 1*100/1000 SFP slot 1 - User manual 1 - Product CD 2 - Wall mounting brackets and screws 1 - DC cable –18 AWG & DC jack 5.5x2.1mm 1.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 2. Hardware Description 2.1 Physical Dimensions Figure 2.1, below, shows the physical dimensions of Antaira’s LNX-0501G-SFP series: 5-port industrial gigabit unmanaged Ethernet switch with 4*10/100/1000Tx and 1*100/1000SFP slot. (W x D x H) is 30mm x 99mm x 142mm Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 2.2 Front Panel The front panel of the LNX-0501G-SFP series industrial gigabit Ethernet switch is shown below in Figure 2.2. Figure 2.2 The Front Panel of LNX-0501G-SFP Series 2.3 Top View Figure 2.3, below, shows the top panel of the LNX-0501G-SFP series switch that is equipped with one 6-pin removal terminal block connector for dual DC power inputs (12~48VDC). Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 2.4 LED Indicators There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific meaning, see below in Table 2.1.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 RJ-45 Pin Assignments (Table 2.2) Pin Number Assignment 1 Rx+ 2 Rx- 3 Tx+ 6 TxTable 2.2 RJ45 Pin Assignments Note “+” and “-” signs represent the polarity of the wires that make up each wire pair. All ports on this industrial Ethernet switch support automatic MDI/MDI-X operation. Users can use straight-through cables (see figure below) for all network connections to PCs, servers, other switches or hubs.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 The following figures show the 10, 100, and 1000 Ethernet RJ-45 pin outs. Figure 2.6 RJ45 Ethernet Port Pin Outs Figure 2.7 Straight-Through Cables Schematic Figure 2.8 Crossover Cables Schematic 2.6 Cabling Use the four twisted-pair, Category 5e or above cabling for RJ-45 port connection. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 To connect the transceiver and LC cable, please follow below steps: First, insert the SFP transceiver module into the SFP slot as shown below in Figure 2.9. Notice that the triangle mark is at the bottom of the SFP slot. Figure 2.10 shows SFP transceiver module was inserted. Figure 2.9 Transceiver to the SFP Module Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 To remove the LC connector from the transceiver, please follow the steps shown below: 1. Press the upper side of the LC connector from the transceiver and pull it out to release as shown below in Figure 2.12. Figure 2.12 Remove LC Connector 2. Push down the metal clasp and pull the transceiver out by the plastic part as shown below in Figure 2.13. Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 2.7 Wiring the Power Inputs Please follow below steps to insert the power wire. 1. Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-) contacts on the terminal block connector as shown below in Figure 2.14. Figure 2.14 Power Terminal Block 2. Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure 2.15. Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 2.8 Wiring the Fault Alarm Contact The fault alarm contact is in the middle of the terminal block connector as the picture shows below in Figure 2.16. By inserting the wires, it will detect the fault status including power failure or port link failure (managed industrial switch only) and form a normally open circuit. An application example for the fault alarm contact is shown below in Figure 2.16. Figure 2.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 3. Mounting Installation 3.1 DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on the switch. Figure 3.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 Follow the steps below to learn how to hang the industrial Ethernet switch. 1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial Ethernet switch. 2. To remove the DIN-Rail bracket, do the opposite from step 1. 3. After the DIN-Rail bracket is installed on the rear side of the switch, insert the top of the DINRail on to the track as shown below in Figure 3.2. Figure 3.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 3.2 Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown below in Figure 3.4. 1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws. 2. Place the wall mounting brackets on the top and bottom of the industrial Ethernet switch. 3. Use the screws to screw the wall mounting bracket on the industrial Ethernet switch. 4.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 4. Hardware Installation 4.1 Installation Steps This section will explain how to install Antaira’s LNX-0501G-SFP series: 5-port industrial gigabit unmanaged Ethernet switch with 4*10/100/1000Tx and 1*100/1000 SFP slot. Installation Steps 1. Unpack the industrial Ethernet switch from the original packing box. 2. Check if the DIN-Rail bracket is screwed on the industrial Ethernet switch.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 5. Network Application This segment provides an example of an industrial Ethernet switch application (Figure 5.1). Figure 5.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 6. Trouble Shooting Verify you have the right power cord or adapter. Never use a power supply or adapter with a non-compliant DC output voltage or it will burn the equipment. Select the proper UTP or STP cable in order to construct the network. Use an unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections: 100Ω Category 5e for 10M/100Mbps.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 7. Technical Specification Table 7.1 has the technical specifications for Antaira’s LNX-0501G-SFP series: 5-port industrial gigabit unmanaged Ethernet switch with 4*10/100/1000Tx and 1*100/1000 SFP slot. IEEE 802.3 10BaseT Ethernet Standard IEEE 802.3u 100BaseTX Fast Ethernet IEEE 802.3ab 1000BaseT IEEE 802.
Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.2 FCC Class A EMI CE EN61000-4-2,3,4,5,6,8,11,12 CE EN61000-6-2 CE EN61000-6-4 IEC60068-2-32 (Free fall) Stability Testing IEC60068-2-27 (Shock) IEC60068-2-6 (Vibration) Safety FCC, CE, UL 61010-1, UL 61010-2-201 UL Class 1 Division 2, ISA 12.12.01 Table 7.
