Specification Sheet

Technology
Standards
IEEE 802.3 10Tx Ethernet
IEEE 802.3u 100Tx Fast Ethernet
IEEE 802.3ab 1000Tx Gigabit Ethernet
IEEE 802.3z Gigabit Fiber
IEEE 802.3x Flow Control for Full Duplex
IEEE 802.3ad for Port Trunk with LACP
IEEE 802.1d STP (Spanning Tree Protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
ITU-T G.8032/Y.1344 ERPS (Ethernet Ring
Protection Switch) Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1x for Network Authentication
IEEE 802.1p QoS/CoS Protocol for Traffic
Prioritization
Switch Properties
Switch
Architecture
Back-Plane (Switching Fabric): 16.0Gbps
Protocol
IGMPv1/v2, SNMPv1/v2c/v3, TFTP, SNTP, SMTP,
RMON, HTTP, HTTPS, Telnet, Syslog, DHCP Option
66/67/82, SSH/SSL, Modbus/TCP, LLDP, IPv4/IPv6
Data Process
Store and Forward
Transfer Rate
14,880pps for 10Base-T Ethernet
148,800pps for 100Base-T Fast Ethernet
1,488,000pps for Gigabit Ethernet
Packet Buffer
4 Mbits
MAC Table
8K
Jumbo Frame
9.6K
Flow Control
IEEE 802.3x for full duplex mode, back pressure for
half duplex mode
VLAN Group
0 ~ 4094
IGMP Group
Up to 256 Groups
Port Interface
Ethernet RJ45
Port
4*10/100/1000Tx auto negotiation speed, Full/Half
duplex mode, and auto MDI connection
Fiber Port
4*100/1000 Dual Rate SFP Slots
Wavelength
Dependent on Fiber type and Distance
RS232 Serial
Console
1*RS232 in RJ45 connector with console cable,
115.2bps, 8,N,1
Configuration
Backup
1*USB 2.0
Protection
Overload
Current
Present
Power
Reverse
Polarity
Present (the unit will not be on, if power reverse)
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable;
100Base-TX: 2-pair UTP/STP Cat. 5 cable. EIA/TIA-
568 100-ohm (100m)
1000BaseTX: UTP/STP Cat.5/5E cable; EIA/TIA-568
100-ohm (100m)
Mechanical Characteristics
LED Indicator
Per Unit: Power 1 & 2 (Green), Fault
(Red)
Housing
Metal IP30 rated
Dimensions
54 x 142 x 99 mm
Weight
Unit: 2.4 lbs
Shipping: 2.9 lbs
Mounting DIN-Rail; Wall-mount (optional)
Power Requirement
Input Voltage 12~48VDC Redundant Input
Power Connection 1 removable 6-contact terminal block
Power
Consumption
15 Watts
Environmental Limits
Operating
Temperature
STD: -10° to 70°C
EOT: -40° to 75°C
Storage
Temperature
-40°C ~ 85°C
Ambient Relative
Humidity
5 to 95%, (non-condensing)
Regulatory Approvals
EMI
FCC Class A
EMS
EN6100-4-2,3,4,5,6,8
EN6100-6-2,4
Free Fall
IEC60068-2-32
Shock
IEC60068-2-27
Vibration
IEC60068-2-6
Green
RoHS Compliant
Certifications
FCC, CE,
UL 61010-1, UL 61010-2-201
Warranty
5 Years
SPECIFICATIONS
