Specification Sheet

LMX-0804G-SFP Series
Features
8-Port Industrial Gigabit Managed Ethernet Switches,
w/4*10/100/1000Tx , 4*100/1000Fx; 12~48VDC Power Input
► Supports 4*10/100/1000Tx, and 4*100/1000Fx Dual Rate
SFP Fiber Slots
► Network Redundancy: STP/RSTP/MSTP, and G.8032 ERPS
(Recovery Time <50ms)
► Supports IPv4/IPv6, and DHCP Option 66/67/82
► Supports Modbus/TCP Protocol for Device Management and
Monitoring
► Configuration: Web Console, Telnet, CLI Command
► IGMP v1/v2 for Multicast Traffic Filtering
► QoS (IEEE802.1p/1Q), CoS/ToS to Increase Determinism
► IEEE802.1Q VLAN for Easy Network Planning
► Enhanced Network Security with IEEE802.1X, SNMP
v1/v2c/v3, HTTPS, and SSH/SSL
► Auto Warning by Exception through E-mail, Relay Output
► Support RMON Function for Efficient Network Monitoring
► Support Port Mirroring for Online Diagnostic
► Operating Temp –STD: -10~70°C, EOT: -40~75°C
► 5-Year Warranty
Antaira Technologies’ LMX-0804G-SFP series is an 8-port industrial managed Ethernet switch that is embedded with
4*10/100/1000Tx Ethernet ports, and 4*100/1000Fx SFP fiber ports that support either Single or Multi-Mode modules. The LMX-
0804G-SFP series is a fully manageable Layer 2 Ethernet switch that is pre-loaded with a user-friendly web management console
design. It supports the ring network redundancy function using the market’s open standard ITU-T G.8032 ERPS (Ethernet Ring
Protection Switch) protocol that has a <50ms network recovery time. The advanced network filtering and security functions, such as,
IGMP, VLAN, QoS, SNMP, port lock, RMON, Modbus TCP, and 802.1X/ HTTPS/ SSH/ SSL increase determinism and improve
network management for remote SCADA systems or control networks.
The LMX-0804G-SFP series is IP30 rated and DIN-rail mountable. There are also two wide operating temperature models for either
a standard temperature range (STD: -10°C to 70°C) or an extended temperature range (EOT: -40°C to 75°C). It also provides high
EFT and ESD protection for industrial networking applications, such as, power/utility, water wastewater, oil/gas/mining, factory
automation, security surveillance within transportation, ITS and any other outdoor or harsh environment.
INTRODUCTION
DIMENSIONS
