Manual
Stand 01/03
* 001207 0 Direkt-Abzug #700.6620 Single-stage trigger #700.6620 5018D
•
* 001206 0 Druckpunkt-Abzug #700.6610 Two-stage trigger #700.6610 5018L
•
* 001208 0 Direkt-Abzug #700.6630 Single-stage trigger #700.6630 5018LD
•
44 003930 0 0 Zylinderschraube Pan head screw 5071-46/1 B1
45 003929 0 0 Zylinderschraube Pan head screw 5071-45/1 B1
50 006431 0 Schaft Stock 1907-8010-00-00 C5
* 005912 0 Schaft, links Stock, left 1807L8010-01-20-1 D5
51 003300 0 0 Widerlager Abutment 1807-55 D1
52 005106 0 0 Senkholzschraube Countersunk head wood screw 4x20 A1
55 002525 0 0 Gelenk Hinges 400-220 B1
56 005150 0 0 Zylinderschraube (2) Cheese head screw (2) M 6x0,75 JGA 40 H1
56a 004934 0 0 Tellerfeder (6) Disc spring DIN 2093 20x8,2x1x1,55 A1
56b 002431 0 0 Scheibe (2) Disc (2) 380-256/1 A1
57 003297 0 0 Schiene Rail 1807-23 E2
58 005118 0 0 Linsensenkschraube (5) Countersunk head screw (5) M 4x30 A1
59 002523 0 0 Abzugbügel Trigger guard 400-215/1 L2
61 005116 0 0 Senkholzschraube Countersunk head wood screw 4x30 A1
62 004073 0 0 Füllstück Rail 6222 B1
68 004548 0 0 Anschütz-Aufkleber Sticker ESK-788 B1
69 005047 0 0 Rampa-Muffe (2) Sleeve (2) 10x12xM5 B1
70a 006422 0 Backe inkl. Rampa-Muffe Cheek piece, incl. sleeve 1907-8100-00-21 M3
* 006421 0 Backe inkl. Rampa-Muffe, links Cheek piece, incl. sleeve, left 1907L8100-00-21 M3
71 001989 0 Backenplatte symmetrisch Cheek piece plate 02213-8200-04-02-3 E3
* 002022 0 Backenplatte symmetrisch, links Cheek piece plate, left 02213L8200-01-00-3 E3
72 004650 0 0 Scheibe (2) Washer (2) 5,3B DIN 125 A1
73 004747 0 0 Zylinderschraube (2) Socket head screw (2) M 5x14 DIN 912 A1
74 001996 0 0 Bolzen (2) Bolt (2) 02213-8200-06-01-4 E1
75 004975 0 0 Sicherungsscheibe Retaining collar 3,2 DIN 6799 A1
76 004745 0 0 Zylinderschraube Socket head screw M 5x12 DIN 912 A1
77 001982 0 0 Backensäule Aluminium Column Aluminium 02213-8200-03-00-3 Q1
78 001990 0 0 Klemmsäule Aluminium Column Aluminium 02213-8200-05-00-4 Q1
69-78+83 001113 0 0 Backenausleger #700.3562 Cheek piece incl. carrier #700.3562 02213-8200-00-02-3
•
79b 005124 0 0 Senkholzschraube (4) Countersunk head wood screw (4) 4,5x50 A1
80a 001873 0 0 Klemmstück (2) Clamp piece (2) 1827-8000-01-00-3 B3
82b 004750 0 0 Zylinderschraube (2) Cheese head screw (2) M 5x18 DIN 912 A1
83 002120 0 0 Mutter (3) Nut (3) 94759-2000-03-00-4 E1
84 002114 0 0 Säule (2) Column (2) 94759-2000-02-00-4 Q1
86 004744 0 0 Zylinderschraube (2) Socket head screw (2) M 5x10 DIN 912 A1
170 002112 0 0 Kappenplatte Hook plate 94759-2000-01-01-3 E3
171 002088 0 0 Mutter Nut 94759-1100-02-01-4 C2
172 002079 0 0 Führung Guide 94759-1000-01-01-4 A3
173 004650 0 0 Scheibe (2) Washer (2) 5,3 DIN 125 A1
173a 002083 0 0 Einlage (2) Insert (2) 94759-1000-02-00-4 B1
174 004745 0 0 Zylinderschraube (2) Cheese head screw (2) M5x12 DIN 912 A1
175 005000 0 0 Senkschraube Countersunk head screw M 5x12 DIN 7991 B1
176 002093 0 0 Unterteil Lower section 94759-1110-01-01-3 N3
177 004957 0 0 Zylinderstift Countersunk head screw 5,0m6x24 B1
178 002102 0 0 Schwenkkappe Swing plate 94759-1120-01-01-3 K3
179 002104 0 0 Einlage Rubber plate 94759-1120-02-00-4 D1
180 002098 0 0 Klemmteil (unten) Clamping piece 94759-1110-04-01-x U1
181 002097 0 0 Klemmteil (oben) Clamping piece 94759-1110-05-01-x U1
182 004990 0 0 Zylinderschraube Countersunk head screw M 6x8 DIN 7984 A1
183 004752 0 0 Zylinderschraube Countersunk head screw M5x22 DIN 912 A1
184 002089 0 0 Haken (schräg) Hook 94759-1100-10-00-3 F3
Nr. / No. 44 - 184
Original-Ersatzteilliste␣ List of component parts
1907/1913 im Schaft 1907 1907/1913 in Stock 1907
1907L/1913L im Schaft 1907L 1907L/1913L in Stock 1907L
Nr. Bestell-Nr. Benennung Description Kennnummer Preisgruppe
No. Order-No. Code number Price group
1907 L
1907
