2/02 Bedienungsanleitung Instruction Leaflet KK-Matchgewehre Small Bore Target Rifles Mod. 1907 · 1912 · 1913 Bitte sorgfältig lesen, bevor Sie dieses Gewehr zusammenbauen oder benutzen. Please read carefully before you assemble or operate this rifle.
Inhaltsverzeichnis Vorwort ......................................................... S.03 Sicherheitshinweise ...................................... S.03 Allgemeiner Umgang mit Gewehren ......... S.04 Gehör- und Augenschutz ............................ S.06 Gesetze ......................................................... S.06 Produktspezifische Sicherheitshinweise ...... S.07 Haftung ......................................................... S.07 Technische Daten ......................................... S.
Preface Dear Friends of ANSCHÜTZ, You have made a good choice, now that you have decided to buy an ANSCHÜTZ product. The many great results obtained with ANSCHÜTZ rifles by target shooters, participants in the Olympic Games as well as in World and European championships throughout the world made your choice easy, as your rifle has benefited from our great experience of making fine sporting and target rifles since 1856.
sequence of disassembly. Should you still have problems with the safe usage and correct handling of your rifle or should you have additional questions, please do not hesitate to contact a competent gunsmith or dealer or address our factory directly. This instruction leaflet is extraordinarily important. Make sure that it is always with the rifle especially when it is sold, lent or otherwise given to a third person. Our products are exclusively meant for target shooting.
Please note: There is no substitute for personal responsibility and common sense in the handling, use and storage of firearms. Securely store your unloaded guns away from access by children or unauthorized adults. General handling of rifles 1. Treat every rifle as though it was loaded. Do not take anyone’s word or automatically assume it is not loaded. Check your rifle personally each time you handle it.
all times and especially when you are not present your rifle is well secured, out of any reach of children, careless adults and other unauthorised persons and in no way accessible to them. Never place any firearm in such a manner that it may be dislodged. For the safe storage of your rifle even in a locked cabinet or safe the use of an additional trigger lock is recommended. Only give your rifle to authorised persons.
2. Make sure there is nobody in the area of case ejection. 3. If you store the rifle remove the bolt and store the bolt uncocked in a separate place. Important note for the handling of ammunition: 1. Exclusively use clean, factory loaded and new ammunition in the caliber approved for your rifle. 2. Be aware that the range of a bullet starting from cal. .22 l.r. might be 1.6 km or even longer. Therefore also be sure of the safety of the impact area. 3.
1907 Light Caliber: Barrel length: Rifling: Total length: Sighting line: Weight: Version: .22 l.r. 66 cm / 25.9“ 66 cm /25.9“ 113 cm / 44.4“ 77 cm / 30.3“ 4,4 kg / 9.6 lbs Einzellader 1913 · 1913 in stock 2213 Caliber: .22 l.r. / .22 l.r. Barrel length: 69 cm / 69 cm 27.1“ / 27.1“ Rifling: 69 cm / 69 cm 27.1“ / 27.1“ Total length: 114-117 cm 112-115 cm 44.8“- 46.0“ 44.09“- 45.27“ Sighting line: 80 cm / 80 cm 31.4“ / 31.4“ Weight: 6,5 kg / 5,6 kg 14.
After assembly for the first time large settlements of the stock wood may occur. Consequently we suggest that you tighten the screws once more in the manner described after some time. Check the the screws before every shooting. signal pin is visible = cocked signal pin uncocked The rifle is •safe, when the „S“ (safe) is visible but the „F“ (fire) is covered •ready for shooting when the „F“ (fire) is visible but the „S“ (safe) is covered.
You can now easily remove the spring support together with the spring by pulling it forward. To reassemble the bolt: Note: the sequence and position of the parts can be seen from the drawing. •First push back the firing pin spring then the front spring support over the firing pin. Push back the spring support until it stops and lock by twisting it slightly either clockwise or counter-clockwise (approx. 1/4 turn). •Hold the bolt body perpendicular to the ground.
To move trigger cam No. 11: •lowest position of the trigger cam: lowest trigger weight •highest position of the trigger cam: highest trigger weight Trigger weight and first stage weight depend on each other with regard to the mechanic mechanism. If one of them is changed there will always be a corresponding change of the other as well. Attention: If the trigger weight is to be more than 200 g, the trigger cam No. 11 must be adjusted to the highest position (turn it by 180° and fix it then).
For the adjustment of the sear engagement for single stage triggers with set screw No. 5 see point 7: 4. First stage (only for single stage triggers): The single stage is the distance between the trigger blade from zero position to the second stage. Adjustment of first stage with set screw No. 4: e r t ui o p a sd f The sear engagement is too long: There is a small distance between the second stage and the release of the trigger. •Turn set screw No.
Attention: The trigger stop set screw No. 8 can be turned over the second stage or first stage function. Malfunction (the trigger does not release)! 6. Adjustment of the trigger blade •Loosen hex screw No. 7 •Trigger blade No. 6 can be moved in the longitudinal guide and can be tilted laterally. 7. Change of two-stage trigger into single stage trigger Adjusting process: •Turn first stage weight screw No. 4 clockwise until you have reached the maximum first stage. •Cock the rifle. •Turn set screw No.
11. Maintenance Please see chapter „Cleaning, maintenance, care, lubrication“. Important note: e r t ui o p a sd f to the left until the cocking piston or firing pin will release again. The trigger does not catch the cocking piston or firing pin: •Set screw No. 4 (first stage) is screwed in too much. •Check to see if the spring is correctly attached and not defective. The first stage trigger is adjusted too tightly: •Turn set screw No. 5 stepwise 1/4 turn to the right until the firing pin is caught.
100 g 100 g 550 g 550 g ● ● ● ● 1607, 1613, 1608 EDS 100 g 100 g 150 g 150 g 550 g 550 g 550 g 550 g 1500 g ● ● ● 700.6550 700.6560 700.6570 700.6580 5071/1 5071/1 D 5075/1 5075/1 D ● 700.6600 700.6610 700.6620 700.6630 700.6640 700.6650 700.6660 700.6670 700.6740 5018 5018 L 5018 D 5018 L D 5020 5020 L 5020 D 5020 L D 5022 700.6800 700.6810 700.6860 700.6870 700.6875 700.6876 700.6877 5098 5098 L 5100 D 5100 L D 5103 5104 5104 L ● ● ● 280 g 280 g 500 g 500 g 1500 g 550 g 550 g 700.
Dry firing device The length of the spring-supported firing pin is adjusted so that it definitely ignites the cartridges. If there is no cartridge or cartridge case in the chamber, the firing pin as well as the rim of the chamber may be damaged when dryfiring for a longer period. In order to prevent any possible damage use either a cartridge case (after about 5 practice shots insert a different case) or preferably the training firing pin 1807T-12.
fore recommend either to use our cleaning rod guide or to clean your gun in a way that it is horizontal or even with the stock up to avoid any contamination of the trigger mechanism. Protect your rifle against dust, sand, humidity, heat and other harmful influences. Vacuum clean your gun case or soft gun case once a month to remove dust and lint. Gun cases and soft gun cases should have a smooth and dust rejecting inner lining. Be aware that condensed water might occur as a result of temperature variations.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1907 1907/1913 in Stock 1907 1907L/1913L im Schaft 1907L 1907L/1913L in Stock 1907L Stand 01/03
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1907 1907/1913 in Stock 1907 1907L/1913L im Schaft 1907L 1907L/1913L in Stock 1907L 1 * 2 * 3 * 4 5 6 * 7 8 9 10 10a 11 * 12 13 14 15 003319 003312 002890 003306 002894 003307 002893 003296 003284 003304 003234 003298 005065 003301 004947 003316 003311 003237 003294 003289 003238 0 16 17 18 19 20 21 22 23 24 25 26 27 28 29 31 32 33 26-33 34 * 34b * 34a 35 * 36 37 38 39 40 41 42 43 003236 003288 003235 003295 003233 000982 004271 00
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1907 1907/1913 in Stock 1907 1907L/1913L im Schaft 1907L 1907L/1913L in Stock 1907L * * * 44 45 50 * 51 52 55 56 56a 56b 57 58 59 61 62 68 69 70a 001207 001206 001208 003930 003929 006431 005912 003300 005106 002525 005150 004934 002431 003297 005118 002523 005116 004073 004548 005047 006422 0 * 71 * 72 73 74 75 76 77 78 69-78+83 79b 80a 82b 83 84 86 170 171 172 173 173a 174 175 176 177 178 179 180 181 182 183 184 006421 001989 002
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1907 1907/1913 in Stock 1907 1907L/1913L im Schaft 1907L 1907L/1913L in Stock 1907L Nr. No. Bestell-Nr. Order-No. 1907 1907 L Nr. / No. 200 - 210 Benennung 200 201 202 203 204 205 206 207 209 210 001131 003601 003603 003602 005011 004754 004750 003600 003560 003605 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Handstop-Riemenbügel #700.3600 Hand stop sling swivel #700.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 2213 1907/1913 in stock 2213 Stand 01/03
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 2213 1907/1913 in stock 2213 Nr. / No. 1 - 50a Bestell-Nr. Order-No.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 2213 1907/1913 in stock 2213 Nr. / No. 51 - 97 Nr. No. Bestell-Nr. Order-No.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 2213 1907/1913 in stock 2213 Nr. / No. 98 - 127 Nr. No. Bestell-Nr. Order-No.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1912 1907L/1913L im Schaft 1912 1907/1913 in stock 1912 1907L/1913L in stock 1912 Stand 01/03
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1912 1907L/1913L im Schaft 1912 1907/1913 in stock 1912 1907L/1913L in stock 1912 1 * 2 * 3 * 4 5 6 * 7 8 9 10 10a 11 * 12 13 14 15 003319 003312 002890 003306 002894 003307 002893 003296 003284 003304 003234 003298 005065 003301 004947 003316 003311 003237 003294 003289 003238 0 16 17 18 19 20 21 22 23 24 25 26 27 28 29 31 32 33 26-33 34 * 34b * 34a 35 * 36 37 38 39 40 41 42 43 003236 003288 003235 003295 003233 000982 004271 004
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1912 1907L/1913L im Schaft 1912 1907/1913 in stock 1912 1907L/1913L in stock 1912 * * * 44 45 51 55 57 58 59 60 60a 62 65 * 68 69 70 * 71 * 001207 001206 001208 003930 003929 003300 002431 003401 005106 003248 005163 005161 004073 005944 005953 004548 005047 005951 005955 001989 002022 0 72 73 74 75 76 77 78 71-78+83 79b 80a 82b 83 71-83 84 86 87 83-87 88 89 90 91 92 88-92 94 95 96 97 98 99 100 101 103 104 004650 004747 001996 004
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1912 1907L/1913L im Schaft 1912 1907/1913 in stock 1912 1907L/1913L in stock 1912 Nr. No. Bestell-Nr. Order-No. 1912 1912 L Nr. / No.
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1913 1907L/1913L im Schaft 1913 1907/1913 in stock 1913 1907L/1913L in stock 1913 Stand 01/03
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1913 1907L/1913L im Schaft 1913 1907/1913 in stock 1913 1907L/1913L in stock 1913 1 * 2 * 3 * 4 5 6 * 7 8 9 10 10a 11 * 12 13 14 15 003319 003312 002890 003306 002894 003307 002893 003296 003284 003304 003234 003298 005065 003301 004947 003316 003311 003237 003294 003289 003238 0 16 17 18 19 20 21 22 23 24 25 26 27 28 29 31 32 33 26-33 34 * 34b * 34a 35 * 36 37 38 39 40 41 42 43 003236 003288 003235 003295 003233 000982 004271 004
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1913 1907L/1913L im Schaft 1913 1907/1913 in stock 1913 1907L/1913L in stock 1913 * * * 44 45 51 55 57 58 59 60 60a 62 66 * 68 69 70 * 71 72 001207 001206 001208 003930 003929 003300 002431 003297 005106 003248 005163 005161 004073 006642 006110 004548 005047 006025 006033 001989 004650 0 73 74 75 76 77 78 71-78+83 79b 80a 82b 83 71-83 84 86 87 83-87 88 89 90 91 92 88-92 94 95 96 97 98 99 100 101 103 104 105 004747 001996 004975 0
Original-Ersatzteilliste␣ List of component parts 1907/1913 im Schaft 1913 1907L/1913L im Schaft 1913 1907/1913 in stock 1913 1907L/1913L in stock 1913 Benennung 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Füllstück klein (28 mm) Filling piece small (28 mm) Füllstück mittel (30,5 mm) Filling piece medium (30,5 mm) Füllstück groß (39 mm) Filling piece large (39 mm) Füllstück XL (49 mm) Filling piece XL (49 mm) Füllstück XL, inkl. Schraube #700.3589 Filling piece XL, incl. screw #700.
