User’s Manual of TC Series Cutting Plotter
Chap 2 Part Names and Functions
2-1 Accessories
2-2 Introduction of main machine
NO. Item Quantity
1 Main machine 1
2 Cutter holder 1
3 Plotter holder 1
4 Refill 1
5 Cutter 3
6 USB cable 1
7 Power cord 1
8 Machine cover 1
9 Operation manual 1
10 Guarantee certificate 1
Note ： There is a free
special machine stand fo
r
the size 800 and large
r
machines.
1.Left cover
2.Cover of guide
3.Panel
4.Pinch roller
5.Carriage
6.Cutting holder
7.Grit roller
8.Right cover
9.Controlling panel
10.Socket of USB port
11.Rubber pillar
12.Power socket
13.Power switch
