User's Manual

7. Appendix
User’s Manual for ION
®
-U Page 55
7.2. Specifications
This manual is valid for the following Remote Units:
ID No Denomination
7698400-xxxx* ION-U H 7P/80-85P/17P/19P
7698400-0001 ION-U H 7P/80-85P/17P/19P VAC
7698400-0002 ION-U H 7P/80-85P/17P/19P VDC
7698400-0003 ION-U H 7P/80-85P/17EP/19P VAC
7698400-0004 ION-U H 7P/80-85P/17EP/19P VDC
* The xxxx suffix is the identifier for the specific configuration of the Remote Unit.
Please refer to the ION-U H 7P/80-85P/17EP/19P data sheet for the ION-U HP RU
specifications.
7.3. Spare Parts
Maintenance of the RU should be performed on an FRU (Field Replaceable Unit)
basis only. If any FRU not contained in the following list needs to be replaced, please
contact customer service for additional instructions.
Designation: ID No
Fan Unit M2-Cabinet 7661556-xx
Optical pigtail, 5 m 7704220
Optical pigtail kit, 5 m 7704209-xx
Pole-mounting kit M2-cab* 7661538
Pole-mounting kit M2-cab* with brackets 7690784
Wall-mounting kit M2-cab* 7661581
* One of the three mounting kits has to be ordered separately. They are not contained within the
standard equipment.
The manufacturer reserves the right to replace the spare parts listed above by
equivalent substitutes.
Note: Only the spare parts listed above are FRUs and can be replaced by the
user. For replacement of any other parts, please send the entire
Remote Unit back to the manufacturer.
7.4. List of Changes
Version Changes Release Date
M0200A8B 30-June-2015
M0200A8C - chapters 1.3 and 4.3.2 updated, duplicate property
damage warning removed
- chapter 1.4 updated, single carrier and Class B
- chapters 4.1 and 6.1 updated, warranty and mounting
kits
- chapter 4.2.2 updated, 50 mm distance
- chapters 4.3.2 and 4.3.5 updated, 4.3-10 torque
wrench
- chapter 6.3 updated, warning
- chapter 7.3 updated, RU IDs added
- chapter 7.3 updated, mounting kits
17-December-2015
M0200A8D - added ION-U H 7P/80-85P/17EP/19P, AWS-3 RU Not yet released
