The Remote Unit, Extension Unit or Master Unit has to be

mounted by proffessionel / special trained installer.

1.1. HIGH POWER RU MECHANICAL INSTALLATIONN

1.1.1. General

Read the health and safety warnings in chapter 1.

WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING

SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT. The installer must verify that the

supporting surface will safely support the combined load of the electronic equipment and all attached

hardware and components. The screws and dowels (wall anchors) used should also be appropriate for

the structure of the supporting wall.

1. Do not install the unit in a way or at a place where the specifications outlined in the Environmental

and Safety Specifications leaflet of the supplier are not met.

2. It is recommended only to use the mounting hardware delivered by the supplier. If different

mounting hardware is used, the specifications for stationary use of the Remote Unit must not be

exceeded.

 Note: Exceeding the specified load limits may cause the loss of warranty!

3. The unit is considerably heavy. Make sure that a suitable mounting surface is used. Ensure there is

adequate manpower to handle the weight of the system.

4. Due to power dissipation, the Remote Unit may reach a very high temperature. Ensure sufficient

airflow for ventilation as specified in the individual mounting procedures.

5. When connecting and mounting the cables (RF, optical, mains, ...) ensure no water can penetrate into

the unit through these cables.

6. Also observe all additional rules or restrictions regarding mounting that depend on the type of

Remote Unit. For details refer to chapter 7.2.2 Mechanical Specification. Install the unit vertically

with the fan unit at the top. A maximum tilt angle of 25° from a vertical position must be kept, as in

the following illustrations:

Summary of content (6 pages)

PAGE 1
Installation Instruction The Remote Unit, Extension Unit or Master Unit has to be mounted by proffessionel / special trained installer. 1.1. HIGH POWER RU MECHANICAL INSTALLATIONN 1.1.1. General Read the health and safety warnings in chapter 1. WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT.
PAGE 2
7. A spacing of 40 mm (1.58 inch) around the unit is required. 8. To ensure sufficient airflow when mounting the unit in enclosed spaces, two lid openings (one for the air inlet and the other for the air outlet) have to be provided. Do not block these air inlets and outlets when mounting the Remote Unit. The size of each opening must equal at least 17 x 17 cm (290 cm2). Make sure, too, there is no thermal short circuit between the air inlet and air outlet.
PAGE 3
1.2. ELECTRICAL INSTALLATION 1.2.1. General Read the health and safety warnings in chapter 1. 1. This unit contains dangerous voltages. Loss of life, severe personal injury or property damage can be the result if the instructions contained in this manual are not followed. 2. It is compulsory to ground the unit before connecting power supply. A grounding bolt is provided on the cabinet to connect the ground-bonding cable. 3.
PAGE 4
14. The unit complies with the surge requirement according to EN 61000-4-5 (fine protection); however, it is recommended to install an additional medium (via local supply connection) and/or coarse protection (external surge protection) depending on the individual application in order to avoid damage caused by overcurrent. 15. Observe the labels on the front panels before connecting or disconnecting any cables! HEALTH AND SAFETY WARNINGS 1.
PAGE 5
12. Warning: For installations, which have to comply with FCC RF exposure requirements, the antenna selection and installation must be completed in a way to ensure compliance with those FCC requirements.
PAGE 6
19. Note: For a Class A digital device or peripheral: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
