6.2. SPECIFICATIONS
6.2.1. Electrical Specifications
ION-M80/90/19P
*
Electrical
Mains powe
r
115 Vac or 230 Vac
Power
supply
Power consumption 530 Watts
Optical
Connectors E2000/APC 8°
Optical return loss 45 dB minimum
Fiber t
y
pe Sin
g
le mode E9/125 mm
Optical link bud
g
et 0 dB to 10 dB
All figures are typical values.
*
An Extension Unit for 1700/2100 MHz (AWS in Extension Unit) can optionally be available.
All data is subject to change without notice.
6.2.2. Environmental and Safety Specifications
) Note: For detailed information, please refer to the Environmental and
Safety Specifications leaflet of the supplier, related to ETS 300 019
(European Telecommunication Standard).
Environmental
Operating temperature range -33° C to +50° C *
RF part IP67
Ingress protection
Fan part IP55
* No passive cooling possible
All data is subject to change without notice.
6.2.3. Mechanical Specifications
Height, width, depth *
831 x 147 x 156 mm
(32.7 x 5.8 x 6.1 inch)
Weight 20 kg (44 Ib)
* Spacing of 40 mm (1.58 in) around unit required
All data is subject to change without notice.
