Installation Guide

CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide M0203A5A_uc
Page 2 © November 2020 CommScope, Inc.
Document Overview
Document Cautions and Notes
This document may contain any of the following notes, cautions, and warning icons.
Abbreviations Used in this Guide
The icon to the left is used to indicate a caution or warning. Cautions and warnings indicate operations or
steps that could cause personal injury, induce a safety problem in a managed device, destroy or corrupt
information, or interrupt or stop services.
The icon to the left indicates a caution or warning that pertains to laser equipment.
The icon to the left indicates a caution or warning that pertains to Radio Frequency (RF).
The icon to the left indicates that the hardware is susceptible to Electro-Static Discharge (ESD) damage.
The icon to the left indicates a caution or warning that pertains to an electrical hazard.
The icon to the left indicates a caution or warning that pertains to a fire hazard.
The icon to the left indicates a Note. Notes provide information about special circumstances.
AC Alternating Current GUI Graphical User Interface
AP Access Point ISDE Innovation, Sciences et Développement économique Canada
AUX Auxiliary ISED Innovation, Science and Economic Development Canada
C Celsius kg Kilogram
CAN Central Area Node LED Light Emitting Diode
CAP H Carrier Access Point, High Power MHz Megahertz
CAP L Carrier Access Point, Low Power mm Millimeter
CAP M Carrier Access Point, Medium Power MMF Multi-Mode Fiber
CAP MX MX Carrier Access Point, Medium Power OPT Optical Transport
Cat Category PoE Power over Ethernet
CAT Copper Transport PN Part Number
CMS CommScope Mobility Solutions RAN Regional-Area Network
