CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide M0203A5A_uc
Page 52 © November 2020 CommScope, Inc.
Installing CAP MXs
Connect the CAP MX Cables
Complete the following procedures in the order in which they are presented. Unless otherwise noted, each
procedure is applicable to a singular CAP MX (not in a cascade), or to a Primary or Secondary CAP MX in a
cascade.
• "Obtain the Required Cable Material” on page 53
• "Connect the CAP MX to an RF Antenna” on page 54
• "Connect the CAP MX to a Classic CAN or TEN” on page 58
• "Connect a Secondary CAP MX (Optional)” on page 58
• "Connect an External Ethernet Device (Optional)” on page 58.
Do not remove protective caps from any of the connectors until instructed to do so.
