M0203A5A_uc CommScope ERA

CAP MX Medium Power Carrier Access Point Installation Guide

DOCUMENT OVERVIEW

This installation guide provides a product overview of and installation instructions for the Medium Power

Carrier Access Point (CAP MX), which allows transmission between CommScope ERA

equipment, antennas,

and Ethernet devices (such as WiFi and IP cameras).

Table 1 lists the CAP MX models that this installation guide supports.

Document Revision History

This is the first release of the CommScope ERA

CAP MX Medium Power Carrier Access Point Installation Guide.

Table 1. Supported CAP MX Models

Part Number

Model Name

7830 1 27 -00 01 CAP MX F -AC- AP E

6/7 E/ 8 0-8 5 /17 E /1 9 /23 /25T

7830 1 27 -00 02 CAP MX F -DC - AP E

6/7 E/ 8 0-8 5 /17 E /1 9 /23 /25T

1 Contact your local sales representative for further information.

For information on other ERA system components, refer to the ERA software and hardware user

documentation, which can be accessed on the CommScope DCCS Customer Portal (see "Accessing ERA

User Documentation” on page 65.)

For information on how to find the minimum software requirements for ERA hardware, refer to

"Hardware to Software Mapping Information” on page 64.
