Installing CAP MXs
Mount Two CAP MXs Using a Dual Mounting Bracket
In this procedure you will mount two CAP MXs back-to-back in one Dual Mounting Bracket. The steps in this
procedure will identify the two CAP MXs as CAP MX-1 and CAP MX-2, as shown in Figure 16.
Figure 16. Two CAP MXs Back-to-Back in a Dual Mounting Bracket
Do the following to mount two CAP MXs in a Dual Mounting Bracket.
1 Obtain the Dual Mounting Bracket (CommScope PN 7839331-xx).
2 Follow the steps in "Unpack and Inspect the CAP MX and Optional Accessories” on page 26. Table 10 lists
the parts that ship with the CAP MX Dual Mounting Bracket.
Table 10. Parts List for CommScope PN 7839331-XX
Description Quantity
Dual Wall Mounting Bracket 1
CAP MX-1
(front of CAP MX-1 faces the mounting surface)
