M0203A5A_uc CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide
© November 2020 CommScope, Inc. Page 31
Installing CAP MXs
Mounting Orientation
Figure 15. Mounting Orientation for a CAP MX
CAP MXs are passively cooled and must therefore always be mounted with its ANT port pointing down, as
shown in Figure 15.
ANT port
pointing down
