M0203A5A_uc CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide
© November 2020 CommScope, Inc. Page 19
Safely Working with ERA Hardware
Required Antenna Distances
Maximum Output Power Levels
Table 6 lists the frequencies and maximum output power for bands supported in the CAP MX variants.
— ISED
WARNING: This is NOT a CONSUMER device. It is designed for installation by an installer approved
by an ISED licensee. You MUST have an ISED LICENCE or the express consent of an ISED licensee
to operate this device.
AVERTISSEMENT: Ce produit N'EST PAS un appareil de CONSOMMATION. Il est conçu pour être
installé par un installateur approuvé par un titulaire de licence d'ISDE. Pour utiliser cet appareil,
vous DEVEZ détenir une LICENCE d'ISDE ou avoir obtenu le consentement exprès d'un titulaire de
licence autorisé par ISDE.
CE
To be sold exclusively to mobile operators or authorized installers - no harmonized frequency
bands, operation requires license. Intended use: EU and EFTA countries.
Indicates conformity with the RED directive 2014/53/EU and/or RoHS directive 2011/65/EU.
CE
Indicates conformity with the RED directive 2014/53/EU and RoHS directive 2011/65/EU certified
by the notified body no. 0700.
Table 5. Required Antenna Distances
Model
Antenna gain
without cable
loss [dBi]
Minimum Distance DL
FCC ISED
m inches m inches
CAP MX 9 0.938 36.93 1.319 51.93
Table 6. Maximum Power Output by Frequency
Band DL Frequency Range Frequency
Power Output
[dBm]
6 617-652 MHz 617 29
7E 728-746 MHz 728
29746-756 MHz 746
758-768 MHz 758
80 862-869 MHz 862
29
85 869-894 MHz 869
17E 2110-2180 MHz 2110
33
2180-2200 MHz 2180
19 1930-1995 MHz 1930
33
1995-2020 MHz 1995
23 2350-2360 MHz 2350 30
25TDD 2496-2690 MHz 2496 32
Table 4. Compliance Labels
Symbol Compliance Meaning
