Safely Working with ERA Hardware
4 Notice: For installations which have to comply with FCC/ISED requirements:
English:
This device complies with FCC Part 15. Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This device complies with Health Canada's Safety Code. The installer of this device should ensure that RF
radiation is not emitted in excess of the Health Canada's requirement. Information can be obtained at
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada's license-exempt RSS(s). Operation is subject to the following two
conditions:
1 This device may not cause interference.
2 This device must accept any interference, including interference that may cause undesired operation
of the device.
Antenna Stmt for ISED:
This device has been designed to operate with antennas that are selected for the location-specific use. The
required antenna impedance is 50 ohms. The maximum Antenna Gain is specified in Table 5 on page 19.
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least the
minimum distance calculated in Table 5 from all persons and must not be co-located or operating in
conjunction with any other antennas or transmitters. Users and Installers must be provided with antenna
installation instructions and transmitter operating conditions to ensure RF exposure compliance.
French:
Cet appareil est conforme avec Sante Canada Code de securite 6. Le programme d'installation de cet
appareil doit s'assurer que les rayonnements RF n'est pas emis au-dela de I'exigence de Sante Canada. Les
informations peuvent etre obtenues:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php
L'emetteur/recepteur exempt de licence contenu dans le present appareil est conforme aux CNR
d'Innovation, Sciences et Developpement economique Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisee aux deux conditions suivantes :
1 L'appareil ne doit pas produire de brouillage;
2 L'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible
d'en compromettre le fonctionnement.
Antenne Stmt pour ISDE:
Cet appareil a ete conçu pour fonctionner avec des antennes selectionnees pour une utilisation specifique
a l'emplacement. L'impedance d'antenne requise est de 50 ohms. Le gain d'antenne maximum est specifie
dans le tableau 5. La ou les antennes utilisees pour cet emetteur doivent etre installees de maniere a
fournir une distance de separation d'au moins la distance minimale calculee dans le tableau 5 de toutes
les personnes et ne doivent pas etre colocalisees ou fonctionner dans en conjonction avec toute autre
antenne ou emetteur. Les utilisateurs et les installateurs doivent recevoir les instructions d'installation
de l'antenne et les conditions de fonctionnement de l'emetteur pour garantir la conformite a l'exposition
RF.
5 Notice: The unit complies with Overvoltage Category II. It also complies with the surge requirement
according to EN 61000-4-5 (fine protection); however, installation of an additional medium (via local
supply connection) and/or coarse protection (external surge protection) is recommended depending on
the individual application in order to avoid damage caused by overcurrent.
