M0203A5A_uc CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide
© November 2020 CommScope, Inc. Page 11
CAP MX Overview
OCTIS RJ45 Reverse Lever Assembly Instructions
Scan the QR code to the right to watch the OCTIS RJ45 connector assembly video.
Figure 6. OCTIS RJ-45 Reverse Lever Assembly Instructions (PN: 7760652)
CommScope GigaSPEED X10D RJ-45 Connector tabs must be removed BEFORE inserting the them into the
OCTIS connectors. For installation instructions, see “Special Instructions for GigaSPEED X10D Connectors”
on page 12.
