No Accurate Position Stored in EEPROM
Decoding Status: Doing Fixes
Disciplining: Phase Locking
PPS Driver Switch: On
PPS Quality: 6.11 ns
PPS Polarity: Positive
10 MHz Quality: -0.14 ppb
Temperature: 35.79 deg C
DAC Value: 85769
DAC Voltage: 0.21 volts
Press any key for more stats.
Pdop: 3.36 Hdop: 2.51
Vdop: 2.24 Tdop: 1.87
Disc Time Constant: 100.0 sec
Disc Damping Fact: 1.200
Hold Over Duration: 0 secs
Receiver mode: Full Position (3D)
Disciplining mode: Normal
Latitude: 38.951807 degrees
Longitude: -77.363371 degrees
Altitude: 117.581690 meters
Fix Dimension: 3D Fix
Fix Mode: Manual
Num Satellites: 5
Satellite PRNs:
24 5 1 7 4
Time Valid: Yes
Yr 2002 Mnth 4 Day 19
Hr 17 Min 2 Sec 59
Timing Flag 0 UTC Offset 13 Week No 1162 Tow 493379
S/W version App Layer: 2.20 [03/16/01]
Core: 10.1 [02/05/99]
Test Result: PASS
Press any key to continue.
Table 2-3 Description of Status Fields
Status Description
Decoding Status: Decoding status of
GPS receiver
Doing Fixes
GPS Time not found
PDOP too high
No usable satellites
Only 1, 2, or 3 usable satellite(s)
Disciplining Activity: Current activity of
the disciplining mechanism
Phase Locking
Oscillator warming up
Frequency locking
Placing PPS
Initializing loop filter
Compensating OCXO
Inactive
PPS Driver Switch:
PPS signal output (Should always be on)
PPS Quality
Estimate of PPS offset to UTC (ns)
