Chapter 2: Preparation for Use
Introduction
This chapter outlines precautions and preparations necessary prior to use of the measurement
system. Unpacking and inspection of the individual pieces, plus the requirements placed on the
external power supply are also covered.
Precautions
Shock Hazard
When replacing the AC fuse on the front panel, be sure to unplug the line cord and replace it with
a fuse of the correct rating and type.
When connecting the DC power cable, be sure to connect the red lead to the positive terminal
and black lead to the negative terminal.
Equipment Modification
This equipment complies with Part 15 of the FCC Rules. Any changes or modifications not
expressly approved by the manufacturer could void the user’s authority to operate the equipment.
Static Sensitive Components
This unit includes integral static discharge protection devices. However, as with any electronic
equipment, care should be taken to not touch connector pins directly.
There are no user serviceable components inside. Units must be returned to the factory for
repairs.
Unpacking and Inspecting
All equipment is packaged in a single shock and vibration protected enclosure.
Examine the carton for signs of damage. If carton appears to be damaged, contact the
transportation agent immediately.
Open the carton and carefully remove each item. Check all items received against the packing
slip and the following Parts List. Examine each item for physical damage, and make a note of
any damages observed.
PARTS LIST
Item P/N
AC Line Cord G15A0518-1
DC Line Cord G15A0519-1
AC Fuse G52A0005-1 4 Amp
DC Fuse G52AF013-30 30 Amp
Manual A002544.G1
External Filter (GWMT 2120 only) G69A0086-1
RF Cable (GWMT 2120 only) G15A0552-1
