Introduction
This document presents description of the Andrew Corporation 850/1900 Band MCPA
(Multi-Carrier Power Amplifier) amplifiers. The MCPA amplifier is a high power,
mixed-mode RF amplifier intended to provide signal amplification and conditioning. The
MCPA amplifier is compatible with GSM/EDGE and WCDMA air interfaces operating
in U.S. domestic cell sites where FCC compliance is mandatory.
The Cell band (869 MHz to 894 MHz) MCPA and PCS band (1.93 GHz to 1.99 GHz) RF
power amplifier capable of amplifying multiple signals of different modulation types to a
composite power level of 160 Watts.
MCPA Specifications
The MCPA1900and MCPA850 provide linear amplification of multi-carrier, mixed-
mode signals in the cellular and PCS frequency bands, respectively. The 850 Band and
1900 Band MCPA, have the following specifications:
Parameter Specification
Operating RF Band
869-894MHz for 800 Band units
1930-1990MHz for 1900 Band
Instantaneous BW
25MHz for all 800 Band
> 45MHz for all 1900 Band
Rated Output Power
@ ≥ +23.5 to 30 VDC input
160W average for -160 units
(Typical: 40W per Carrier for CDMA /WCDMA and
25W per Carrier for GSM/EDGE/TDMA)
Rated Output Power
@ ≥ +21.0 to < +23.5 VDC
105W average
Input signal types TDMA, GSM/EDGE, WCDMA, CDMA/EVDO
DC power Nominal input voltage is +27VDC
DC voltage input range +21VDC to +30VDC normal
DC-RF Efficiency 18% typical for 160w versions
Physical dimensions 18.5” x 17.25” x 3.75”
Weight 35 pounds, typical
Cooling technique
Integral Fans Front-mounted, full fan tray may be
replaced without PA module removal from sub rack and
without disrupting service.
