3.5. Bill of Materials (BOM)
Table 16 - Bill of Material
Item
Ref Des
Qty
Description
Comment
1
C1, C6,
C7, C8,
C11
4/1 NP
CAP CER 0.1UF 10V 10% X5R 0402
C1 not populated
2
C2
1
CAP CER 0.01UF 50V 10% X7R 0402
3
C3, C4
2
CAP CER 47PF 50V 5% NPO 0402
4
C5
1 NP
CAP CER 1000PF 50V 10% X7R 0603
Not populated
5
C9, C12
2
CAP CER 4.7UF 6.3V 10% X5R 0402
6
C10
1
CAP CER 1000PF 50V 5% NP0 0402
7
J1, J2, J3,
J4
2/2 NP
CONN SOCKET 10POS 0.1" SNGL
J3, J4 not populated
Samtec
ESQ-110-13-S-S
(or equivalent)
8
J5
1 NP
CONN HEADER 10POS 1.27MM
DUAL ROW VERTICAL T/H
SHROUDED
Not populated
Samtec
SHF-105-01-L-D-TH
(or equivalent)
9
J6
1
CONN USB 2.0 MINI-B
Samtec
MUSBR-05-S-O-B-SM-A
(or equivalent)
10
J7
1
CONN HEADER 2POS 2.54MM
SINGLE ROW VERTICAL T/H
Samtec
MTLW-102-07-T-S-230
(or equivalent)
11
J8
1
CONN HEADER 6POS 2.54MM
SINGLE ROW VERTICAL T/H
Even row not populated
Samtec
MTLW-106-07-T-S-230
(or equivalent)
12
JP1, JP2
(HDR)
2
CONN HEADER 2POS 2MM
SINGLE ROW VERTICAL T/H
Harwin
M22-2510205
(or equivalent)
13
JP3, JP4
(HDR)
2
CONN HEADER 3POS 2MM
SINGLE ROW VERTICAL T/H
Harwin
M22-2510305
(or equivalent)
14
JP1, JP2,
JP3, JP4
(SHUNT)
4
CONN SHUNT 2MM 2POS GOLD
Samtec
2SN-BK-G
(or equivalent)
15
LED1,
LED4
2
LED 0402 RED SMD
Kingbright
APHHS1005SURCK
(or equivalent)
16
LED2
1
LED 0402 GREEN SMD
Kingbright
APHHS1005CGCK
(or equivalent)
