2.1.3. Optional Hardware Components
The AIR B-Smart BoosterPack supports additional hardware features which are not populated
by default. Refer to section 3.2 and its sub-sections for more information regarding these
optional hardware components.
Figure 5 - Optional Hardware Components
Radio Module Test Points (J8)
LaunchPad Interface Connector (J4)
MCU Reset Pushbutton Switch (S5)
MCU Socket (X1)
MCU User Pushbutton Switch (S4)
LaunchPad Interface Connector (J3)
MCU Green Status LED (LED6)
MCU Red Status LED (LED5)
Radio Module Programming Header (J5)
