Owner manual

INTRODUCTION

1-1. THE SMART MATRIX OPERATING MODE

Native Matrix Mode

Before you start setting up your Smart MatriX (SMX200) for the rst time, be sure you know what you actually

want to do with it. The Smart MatriX offers one operating mode, which results in a versatile video production

tool for live event staging and xed installation applications.

* NOTE * : We recommend resetting the device to its default values every time you set up your shows or

events (see the “Operating The Smart MatriX” chapter, p28).

This mode turns your Smart MatriX into a true 12 x 2 High End Scaled Matrix, while preserving seamless

switching capabilities. Main and Preview outputs can be set to different resolutions and rates. Switching

between any of the inputs can be done with the various effects (Cut, Fade, Slides…) and synchronized on

both outputs.
