Owner manual

Source Input selection
Plug your sources thanks to the 6 universal inputs, 2 DVI-I Inputs or 4 SDI inputs.
Don’t forget that the 2 DVI-I inputs can be used with DVI-D computer sources (DVI #1 & DVI #2) but also with
a DVI-A adaptor for analog sources too (source #5 & #6) shipped with your unit.
Be sure that all connectors are rmly attached using all available locking screws.
To set up your inputs:
Input menu → Auto settings
You can also do it manually on each input# using the ENTER and the Knob button and set up the inputs type
one by one.
You can also check your actual input conguration using the cong status:
Input menu → Cong Status
You can nd several settings for each input (some settings are specic to some signal type):
- Type: to set up your input type (Computer, Video etc..)
- Enabled/disabled: to enable/disable input#
- Audio input: to set up the audio regarding the input
- H Sync. load: to change the load of the Sync. signal (Hi-Z, 75 ohms)
- EDID: to set up the EDID in terms of resolution and rate
- Status: to summarize the input status
Concerning the DVI inputs, a specic feature allows enable/disable the HDCP receiver for the input chosen.
It can be very useful especially using a Mac:
Input menu → DVI # → HDCP detection
* NOTE * : The input status is available at any time in status input menu and can give you information
about format rate and HDCP.
Input selection settings
SETTINGS IN NATIVE MATRIX MODE
The advanced features of SMX200 are available by the external remote control as:
- Remote Control Sofware - Ref. RCS (supplied)
- Remote Control Keypad - Ref. RK-300
- Triple Remote Control Keypad - Ref. TRK-800
- Orcherstra - Ref. ORC50
- Axion2 - Ref. ARC200
