3-1. CONNECTING THE SMART MATRIX
The Smart MatriX can be set up with up to 12 different sources, and will drive up to 2 digital DVI-D sources,
2 SD-SDI sources and 8 analog computer/video sources simultaneously. The versatility of the Smart MatriX
will allow for almost any event conguration and cater for all your projection needs.
The intuitive rear panel of the Smart MatriX will let you set up for the rst time quickly and easily. Here is an
example of a typical Smart MatriX setup.
CONNECTING THE SMART MATRIX
23
