Owner manual

• DVI (Digital Video Interface) OUTPUTS
Connector: Outputs #1 & #2: female DVI-I (digital pins).
Signal: Digital Visual Interface (DVI)-TMDS single link.
Resolutions:
Format Ratio Refresh Rate Reduced Blanking
640 x 480 4 : 3 50Hz 60Hz 72Hz 75Hz
800 x 600 4 : 3 50Hz 60Hz 72Hz 75Hz
848 x 480 16 : 9 50Hz 60Hz 72Hz 75Hz
1024 x 768 4 : 3 50Hz 60Hz 72Hz 75Hz
1280 x 720 16 : 9 50Hz 60Hz
1280 x 768 15 : 9 50Hz 60Hz 72Hz 75Hz
1280 x 800 16 : 10 50Hz 60Hz 72Hz 75Hz
1280 x 1024 5 : 4 50Hz 60Hz 72Hz 75Hz
1360 x 768 16 : 9 50Hz 60Hz 72Hz 75Hz
1366 x 800 15 : 9 50Hz 60Hz 72Hz 75Hz
1400 x 1050 4 : 3 50Hz 60Hz 72Hz 75Hz
1440 x 900 16 : 10 50Hz 60Hz 72Hz 75Hz
1600 x 1200 4 : 3 50Hz 60Hz
1680 x 1050 16 : 10 50Hz 60Hz
1920 x 1080 16 : 9 50Hz 60Hz 72Hz 75Hz YES
1920 x 1080 B 16 : 9 50Hz 60Hz YES
1920 x 1080 C 16 : 9 50Hz 60Hz YES
1920 x 1080 HD 16 : 9 50Hz 60Hz YES
1920 x 1200 16 : 10 50Hz 60Hz YES
2048 x 1080 19 : 10 50Hz 60Hz YES
• AUDIO OUTPUT
Connector: Output #1 and #2: 2 Balanced or unbalanced
mono/stereo outputs (on 5-pin MCO male connector).
Vo max: Unbalanced = +15dBu (at 300Ω load)
Balanced = +21dBu (at 600Ω load)
Zo = 600Ω balanced
Zo = 300Ω unbalanced
G = 0 dB nominal
4
L+
L-
R+
R-
BALANCED
L+
R+
L-
R-
GROUND(S)
Outputs #1 to #2: Balanced & unbalanced connection
The video output generates a SDI signal in which is embedded only one stereo audio stream.
Settings Availability
Gain
Yes: from -
∞
to+18dB
Balanced Audio Left and Right
Auxiliary Input Mixing Yes
Adjusting Audio Delay Yes: from 0 to 80ms (Automaticaly or Manual)
