CD RESPONSE COMMAND DESCRIPTION TYPE
VALUE
MIN MAX DESCRIPTION
STATUS COMMANDS
UN UN MeasuresunityintensofkHz. Rd 0 65535 ex:14500=145MHz
IL IL Horizontalperiodofinputsignal(M) Rd 0 65535 Linefrequency(inkHz)=(UNVALUE)x10÷ (IL VALUE).
il il Horizontalperiodofinputsignal(P) Rd 0 65535 Linefrequency(inkHz)=(UNVALUE)x10÷ (il VALUE).
ID ID Verticalperiodofinputsignal(M) Rd 0 65535 Framefrequency(inHz)=(LinefrequencyinHz)÷ (ID VALUE).
id id Verticalperiodofinputsignal(P) Rd 0 65535 Framefrequency(inHz)=(LinefrequencyinHz)÷ (id VALUE).
IP IP InputSync.detection(M).  Rd 0 1 0=noSync.detected 1=Sync.detected.
ip ip InputSync.detection(P).  Rd 0 1 0=noSync.detected 1=Sync.detected.
IH IH SignofthehorizontalinputSync.(M) Rd 0 1 0=negative  1=positive.
ih ih SignofthehorizontalinputSync.(P) Rd 0 1 0=negative  1=positive.
IV IV SignoftheverticalinputSync.(M) Rd 0 1 0=negative  1=positive.
iv iv SignoftheverticalinputSync.(P) Rd 0 1 0=negative  1=positive.
         0=SeparateH&Vsync.
IK IK InputSynctypedetection(M). Rd 0 3 1=Compositesync.(TTL).
ik ik InputSynctypedetection(P). Rd 0 3 2=SOG(Sync.OnGreen).
3 = Composite sync. (analog).
II II Interlacedsignaldetection(M). Rd 0 1 0=notinterlaced  1=interlaced.
ii ii Interlacedsignaldetection(P). Rd 0 1 0=notinterlaced  1=interlaced.
IO IO "Outofrange"signaldetection(M). Rd 0 1 0=Inrange  1=Outofrange.
io io "Outofrange"signaldetection(P). Rd 0 1 0=Inrange  1=Outofrange.
         0=nosignal  1=wrongsignal
         2=NTSCstd(3.58/60) 3=PALstd(4.43/50)
         4=SECAM(50Hz) 5=B&W(50Hz)
         6=B&W(60Hz)  7=YUV50Hz
         8=YUV60Hz  9=RGB50Hz
         10=RGB60Hz  11=640x480
IF IF Standardinputsignaldetection(M). Rd 0 35 12=800x600  13=1024x768
         14=1280x1024  15=1400x1050
         16=1600x1200  17=852x480
if if Standardinputsignaldetection(P). Rd 0 35 18=1280x720  19=1280x768
         20=1366x768  21=1680x1050
         22=1920x1080  23=1080i50
         24=1080i60  25=720p50
         26=720p60  26=1080p24
         28=1080p25  29=1080p30
         30=1080p50  31=1080p60
         32=1080sf24  33=480p50
         34=480p60  35=480p72
XA XA Synchronizedinput.  Rd 0 8 IdenticalasXRcommand.
XF XF Synchronizedinputstandard(M). Rd 0 29 IdenticalasIFcommand.
XT REFT Frame frequency of the synchro-
  nizedinput(M).   Rd 0 65535 ValueinhundredthofHz.
OTHERS COMMANDS
TP TP T-BARposition.   Rd/Wr 0 255
TB TB Executedpercentageoftheeffect. Rd 0 65535 0=0%   65535=100%
? DEV Devicetype.   Rd 0 65535
# #1,....#0 Sendalldeviceparameters.  Rd  
NOTE : (M) = MAIN output. Rd/Wr = Read and write command. (P) = PREVIEW output. Rd = Read only command.
