Manual

CD RESPONSE COMMAND DESCRIPTION TYPE
VALUE /VALEUR
MIN MAX DESCRIPTION
CONTROLS COMMANDS
YE YE  Eraseallmemories. Rd/Wr 0 1 1=eraseallmemories(automaticreset).
YI YI  Auto-lock  Rd/Wr 0 1 0=off  1=on.
SR SR  RedadjustmentoftheFADE. Rd/Wr 0 255
SG SG  BlueadjustmentoftheFADE.Rd/Wr 0 255
SB SB  GreenadjustmentoftheFADE.Rd/Wr 0 255
SW SW  Transition.  Rd/Wr 0 5 0=fadecolor 1=cleancut
2 = frame 1 3 = frame 2
4= frame 3 5 = frame 4
YL YL  Syncloss  Rd/Wr 0 15 0=black 1=input1
2 = input 2... 8 = input 8
         9=frame1... 10=frame2
12 = frame 3... 15 = frame 6
xi xi  Identicationnumberbyte0&1Rd 0 65535
xj xj  Identicationnumberbyte2&3 Rd 0 65535
xk xk  Identicationnumberbyte4&5 Rd 0 65535
xl xl  Identicationnumberbyte6&7 Rd 0 65535
xU VERU  Updateversion.  Rd 0 65535 Example:VERU104=version1.4
YR YR  DEFAULTVALUE.  Rd/Wr 0 1 1=Defaultvalueaction(automaticreset).
COMMUNICATION COMMANDS
ne ne  CommunicationportselectionRd/Wr 0 1 0=RS232 1=LAN
nr nr  ResetoftheLANparameters.Rd/Wr 0 1 1=reset.
ns ns  StoretheLANparameters. Rd/Wr 0 1 1=store.
na na  IPaddressandportselection Rd/Wr 0 3 0=allIPaddress/ports
   (formodication)     1=IPlocaladdress/localport
2 = IP remote address / remote port
3 = IP gateway address.
nw nw First byte of the address
   selectedbythenacommand. Rd/Wr 0 255
nx nx Second byte of the address
   selectedbythenacommand. Rd/Wr 0 255
ny ny Third byte of the address
   selectedbythenacommand. Rd/Wr 0 255
nz nz Forth byte of the address
   selectedbythenacommand. Rd/Wr 0 255
np np  Numberoftheport(localor Rd/Wr 0 65500 localport:10000to10999.
   orremote)selectedbythe    remoteport:0to65500.
na command.
nk nk  netmask.   Rd/Wr 0 24 Value=numberofbitto0(fromright).
         example:2►255.255.255.252
          3►255.255.255.248
.............
          8►255.255.255.0.........
          24►255.0.0.0
nt TCP  protocolselection.  Rd/Wr 0 1 0=UDP 1=TCP
NOTE : (M) = MAIN output. Rd/Wr = Read and write command. (P) = PREVIEW output. Rd = Read only command.
PAGE50
