CD RESPONSE COMMAND DESCRIPTION TYPE

VALUE

MIN MAX DESCRIPTION

FRAME & LOGOS COMMANDS

LM LM Frame/logomode.   Rd/Wr 0 3 0=use&assignmentmode.

1 = logo recording mode.

2 = animated logo recording mode

3 = frame recording mode.

4 = erasing logo mode.

5 = erasing frame mode.

6 = logo transfer mode.

LX LX Statusofthelogoprogrammer  Rd 0 4 0=free.

1 = logo/frame in recalling process.

2 = logo/frame in storing process.

3 = output format incompatible with the logo.

4 = logo/frame in erasing process.

LA LA Logoindex#1assignment.  Rd/Wr 0 9 0=nologo

1 = logo 1... 8 = logo 8

         9=animatedlogo

LB LB Logoindex#2assignment.  Rd/Wr 0 9

LF LF Frameassignment.   Rd/Wr 0 4 0=noframe

1 = frame 1 2 = frame 2

3 = frame 3 4 = frame 4

LC LC • In logo recording mode :

number of the logo to be store (1 to 8).

• In frame recording mode :

  numberoftheframetobestore(1to4). Rd/Wr 0 8 Inerasemode:0=eraseall

• In erase logo mode :

number of the logo to be erase (1 to 8)

• In erase frame mode :

number of the frame to be erase (1 to 4).

LD LD Displaylogo(accordingtoPCH) Rd/Wr 0 1 0=DisplayOFF  1=DisplayON

LU LU Horiz.positionofthelogostoringarea. Rd/Wr 0 255

Lu Lu Vert.positionofthelogostoringarea. Rd/Wr 0 255

LK LK Horizontalsizeofthelogostoringarea. Rd/Wr 5 255 5=3%   255=100%

Lk Lk Verticalsizeofthelogostoringarea. Rd/Wr 5 255 5=3%   255=100%

LQ LQ Pixelsnumberinalineofthestoringarea.Rd 0 65535

Lq Lq Linesnumberofthestoringarea. Rd 0 65535

LH LH Horizontalpositionofthelogo1(M). Rd/Wr 0 255

LV LV Verticalpositionofthelogo1(M). Rd/Wr 0 255

LW LW Logo1horiz.size%outputformat(M). Rd 5 255 5=3%   255=100%

LS LS Logo1vert.size%outputformat(M). Rd 5 255 5=3%   255=100%

LT LT Logo1type(M).   Rd 0 2 0=incrustinglogo

1 = cutting logo

2 = animating logo

LP LP Pixelsnumberinalineoflogo1(M). Rd 0 65535 These2commandsallowcalculatingthedurationofthestoring.

LL LL Linesnumberinalogo1(M).  Rd 0 65535

Lh Lh Horizontalpositionofthelogo2(M). Rd/Wr 0 255

Lv Lv Verticalpositionofthelogo2(M). Rd 0 255

Lw Lw Logo2horiz.size%outputformat(M) Rd 5 255 5=3%   255=100%

Ls Ls Logo2vert.size%outputformat(M) Rd 5 255 5=3%   255=100%

Lt Lt Logo2type(M).   Rd 0 2 0=incrustinglogo

1 = cutting logo

2 = animating logo

Lp Lp Pixelsnumberinalineoflogo2(M). Rd 0 65535 These2commandsallowcalculatingthedurationofthestoring.

Ll Ll Linesnumberinalogo2(M).  Rd 0 65535

LN LN Pixelsnumberinalineofaframe(M) Rd 0 65535

Ln Ln Linenumberofaframe(M).  Rd 0 65535

NOTE : (M) = MAIN output. Rd/Wr = Read and write command. (P) = PREVIEW output. Rd = Read only command.

PAGE 48
