Manual

CD RESPONSE COMMAND DESCRIPTION TYPE
VALUE
MIN MAX DESCRIPTION
IMAGE COMMANDS
yC yC Automaticcentering(M).  Rd/Wr 0 1 1=centeringaction(automaticreset).
HP HP Horizontalposition(M).  Rd/Wr 0 255
VP VP Verticalposition(M).  Rd/Wr 0 255
HW HW Horizontalsize(M).  Rd/Wr 0 255
VS VS Verticalsize(M).   Rd/Wr 0 255
BR BR Brightnessadjustment(M).  Rd/Wr 0 255
CT CT Contrastadjustment(M).  Rd/Wr 0 255
CL CL Coloradjustment(M).  Rd/Wr 0 255
HU HU Hueadjustment(M).  Rd/Wr 0 255
QP QP Sharpnessadjustment(M).  Rd/Wr 0 7 0=level1... 7=level8.
OV OV Underscan/overscan(M)  Rd/Wr 0 1 0=underscan 1=overscan
IA IA Inputaspectratioselection(M) Rd/Wr 0 2 0=4/3  1=16/9
         2=16/9anamorphic
OA OA Outputaspectratio(M)  Rd/Wr 0 3 0=1:1 1=crop 2=Fullscreen 3=zoom.
ZW ZW Zoom:horizontalsize(M).  Rd/Wr 10 200 10=10%
         100=100%(nozoom) 200=200%
ZS ZS Zoom:verticalsize(M).  Rd/Wr 10 200 10=10%
         100=100%(nozoom) 200=200%
ZH ZH Zoom:horizontalposition(M). Rd/Wr 0 255
ZV ZV Zoomverticalposition(M).  Rd/Wr 0 255
QR QR Redleveladjustment(M)  Rd/Wr 0 255
QG QG Greenleveladjustment(M)  Rd/Wr 0 255
QB QB Bleuleveladjustment(M)  Rd/Wr 0 255
MC CLK Numberofpixelsperline(M)  Rd/Wr 0 65535
MP PHA Pixelsphaseadjustment(M)  Rd/Wr 0 31
yP yP PRESET(M).   Rd/Wr 0 1 1=PRESETaction(automaticreset).
yc yc Automaticcentering(P).  Rd/Wr 0 1 1=centeringaction(automaticreset).
hp hp Horizontalposition(P).  Rd/Wr 0 255
vp vp Verticalposition(P).  Rd/Wr 0 255
hw hw Horizontalsize(P).   Rd/Wr 0 255
vs vs Verticalsize(P).   Rd/Wr 0 255
br br Brightnessadjustment(P).  Rd/Wr 0 255
ct ct Contrastadjustment(P).  Rd/Wr 0 255
cl cl Coloradjustment(P).  Rd/Wr 0 255
hu hu Hueadjustment(P).  Rd/Wr 0 255
qp qp Imageprocessadjustment(P) Rd/Wr 0 7 0=level1... 7=level8.
ov ov Underscan/overscan(P)  Rd/Wr 0 1 0=underscan 1=overscan
ia ia Inputaspectratioselection(P) Rd/Wr 0 2 0=4/3  1=16/9
         2=16/9anamorphic
oa oa Outputaspectratio(P)  Rd/Wr 0 3 0=1:1  1=crop
2 = Full screen 3 = zoom.
zw zw Zoomhorizontalsize(P).  Rd/Wr 0 255 0=100% 255=200%
zs zs Zoomverticalsize(P).  Rd/Wr 0 255 0=100% 255=200%
zh zh Zoomhorizontalposition(P).  Rd/Wr 0 255
zv zv Zoomverticalposition(P).  Rd/Wr 0 255
qr qr Redleveladjustment(P)  Rd/Wr 0 255
qg qg Greenleveladjustment(P)  Rd/Wr 0 255
qb qb Bleuleveladjustment(P)  Rd/Wr 0 255
mc mc Numberofpixelsperline(P)  Rd/Wr 0 65535
mp mp Pixelsphaseadjustment(P)  Rd/Wr 0 31
yp yp PRESET(P).   Rd/Wr 0 1 1=PRESETaction(automaticreset).
YS YS STORE.    Rd/Wr 0 1 1=STOREaction(automaticreset).
NOTE : (M) = MAIN output. Rd/Wr = Read and write command. (P) = PREVIEW output. Rd = Read only command.
PAGE 46
