8-2. DISPLAY OUTPUTS
8-3. AUDIO INPUTS
8-4. MAIN AUDIO OUTPUT
8-5. PRELIST AUDIO OUTPUT
• MAIN ANALOG
Connectors : HD15 and DVI-I (2x buffered).
Resolution:  4/3&5/4:800x600,1024x768,1280x1024,1400x1050,1600x1200.
   16/9&16/10:852x480,1280x720,1280x768,1366x768,1920x1080.
Framefrequency: 50,60,72***,75***Hzandfollow(*** = not available for all resolutions).
Sync. types : RGBHV, RGB/S, RGsB (Sync On Green).
Levels:  R,G,B=0.7Vp/p.
H & V Sync = TTL
   CompositeSync=TTLand0.3V.
   SOG(SyncOnGreen)=0.3V.
Impedance : R, G, B = 75 ohms.
• MAIN DIGITAL
Connector : DVI-I.
Format : Digital Visual Interface (DVI). TMDS Single link.
Resolution : Upto1600x1200@60Hz.
• PREVIEW
Connectors : HD15.
Format:  XGA/60Hz.
Sync. types : RGBHV.
Levels:  R,G,B=0.7Vp/p.
H & V Sync = TTL
Impedance : R, G, B = 75 ohms.
Connectors : Jack 3.5 mm (inputs #1, 2 & 8) and MCO (inputs #3, 4, 5, 6, 7 & AUX).
Type : Stereo balanced (inputs 7 & AUX) & unbalanced.
Levels : Vi = + 18 dBu (max).
   Zi=20kΩunbalanced.
   Zi=40kΩbalanced.
Gain : Adjustable.
Connectors : MCO.
Type : Stereo balanced & unbalanced.
Levels : Vo = + 18 dBu max (unbalanced).
   Zo=300Ω(unbalanced).
Vo = + 24 dBu max (balanced).
   Zo=600Ω(balanced).
Gain:   0dB nominal (adjustable with Master volume).
Connectors : Jack 3.5 mm.
Type : Unbalanced.
Levels : Vo = + 18 dBu max.
   Zo=300Ω.
Gain:   0dB nominal (adjustable with Master volume).
