TECHNICAL SPECIFICATIONS

• ANALOG COMPUTER

Connectors : HD15 (inputs #2 to 8) and DVI-I (input #1).

Linefrequency: Upto110kHz.

Framefrequency: Upto130Hz.

Resolution:  Upto1600x1200/60Hz.

Sync. types : RGBHV, RGB/S, RGsB (Sync On Green).

Levels:  R,G,B=0.7Vp/p.

H & V Sync = TTL

   CompositeSync=TTLand0.3V.

   SOG(SyncOnGreen)=0.3V.

Impedance : R, G, B = 75 ohms.

H = 75 Ohms or Hi-Z.

V = Hi-Z.

• DIGITAL COMPUTER INPUT

Connectors : DVI-I (input #1).

Format : Digital Visual Interface (DVI)

TMDS single link.

Resolution : Upto1600x1200/60HzRB(reducedblanking)and1920x1080/60Hz.

• RGB/S VIDEO

Connectors : HD15 (inputs #2 to 8) and DVI-I (input #1).

Frequency:  15.625kHz/50Hz(625lines).

   15.734kHz/60Hz(525lines).

Levels:  R,G,B=0.7Vp/p.

   SYNC.=0.3Vp/porTTL.

Impedance : RGB = 75 ohms.

SYNC. = 75 Ohms or Hi-Z.

• COMPONENT

Connectors : HD15 (inputs #2 to 8) and DVI-I (input #1).

Frequency:  15.625kHz/50Hz(625lines).

   15.734kHz/60Hz(525lines).

Levels:  Y=1Vp/p(0.7VLuma+0.3VSync.).

   R-Y=0.7Vp/p.

   B-Y=0.7Vp/p.

Impedance : Y, R-Y, B-Y = 75 Ohms.

• HDTV

Connectors : HD15 (inputs #2 to 8) and DVI-I (input #1).

Formats:  HD-YUV(1080i/60-50Hz,1080p,720p/60-50Hz,480p/60Hz).

Levels:  Y=1Vp/p(0.7V+sync.).

   R-Y=1Vp/p(0.7V+sync.).

   B-Y=1Vp/p(0.7V+sync.).

Sync.:   Tri-level:±0.3V(positive/negative).

   Bi-level:0.3V(negative).

Impedance : 75 Ohms.

• S.VIDEO

Connectors : 4-pin mini DIN (input #8), BNC (input #7), HD15 (inputs #2 to 8) and DVI-I (input #1).

Standards:  PAL(15.625kHz/50Hz–625lines)orNTSC(15.734kHz/60Hz–525lines).

Levels : Y = 1 Vp/p.

   C=0.3Vp/p.

Impedance: 75 Ohms.

• COMPOSITE VIDEO

Connectors : BNC (input #7), RCA (input #8), HD15 (inputs #2 to 8) and DVI-I (input #1).

Standards:  PAL/SECAM(15.625kHz/50Hz–625lines)orNTSC(15.734kHz/60Hz–525lines).

Level : 1 Vp/p.

Impedance : 75 Ohms.
