 MAC address : The MAC address, also referred to hardware address, is a unique number assigned to each device.
The MAC address is available on the bottom device label.
9-6 [key locking] + ENTER.
 Selectanitemwith◄►andchangethemodewithENTER.
• [All] : Locks/unlocks all the front panel switches.
• [Menus] : Locks/unlocks the LCD CONTROL switches.
• [autolock] : Allows selecting an input only if a signal is connected.
• [Input] : Locks/unlocks the INPUT SELECTION and FREEZE switches.
NOTE : To unlock press simultaneously ENTER and EXIT.
9-7 [Stand-by] + ENTER.
9-7-1 [Baud rate] + ENTER.
 Selectthebaudrateofthedisplaydevicewith◄►+ENTER(9600,2400&1200).
9-7-2 [Message ON] + ENTER.
This function allows to store the ON message of your display device. Whenever your device goes out of stand-
bymodeitwillsendthestoredmessagetoyourdisplaydevice.TheONmessagecanbecomposedofupto50
bytes.Foreachbyte,selecttherequiredASCIIcodewith◄►andvalidatewithENTER.
NOTE : The 0 value allows to display : no data.
9-7-3 [Message OFF] + ENTER.
This function allows to store the OFF message of your display device. Whenever your device goes out of stand-
by mode it will send the stored message to your display device. The OFF message can be composed of up to
50bytes.Foreachbyte,selecttheneededASCIIcodewith◄►,thenpressENTER.
NOTE : The 0 value allows to display: no data.
9-7-4 [Reset mess ON] + ENTER.
Allows to reset the ON message.
9-7-5 [Reset mess OFF] + ENTER.
Allows to reset the OFF message.
9-7-6 [Stand by time] + ENTER.
When the device doesn't detect any signal on the selected input, it sets itself to STANDBY mode after the dura-
tionofyourchoice.Selectadurationwith◄►+ENTER.
NOTE : Select OFF to inactivate this function.
9-7-7 [Stand by] + ENTER.
Allows to set the device to STANDBY mode. To get out of STANDBY mode, press one of the front panel buttons.
9-8 [Erase memories] + ENTER.
This function allows erasing all NON-volatile image memories. Select [YES] and validate with ENTER.
9-9 [Default value] + ENTER.
This function allows setting the following functions to the factory settings. Select [YES] and validate with ENTER.
FUNCTION POSITION
input type Computer HV/C.
used input All used.
H sync load All Hi-Z.
VCR mode All off
outputformat  SXGA60Hz4/3.
Output sync H&V.
type of screen 4/3
test pattern no
switching seamless #1
pos.settings  0
aspect ratio in 4/3
aspect ratio out 1:1
brightness 128
black level 128
contrast 128
color 128
hue 128
under/overscan overscan
sharpness 3
mastervolume  192
audio source auto follow
audio level 48
audio balance 32
auxiliary input OFF
mute OFF
display logo all ON
assignment all none
key locking all unlock
fadecolor   R,G,B=0
RS232/LAN port RS232
