5-5. FUNCTIONS DESCRIPTION
1►[SWITCHING] + ENTER.
1-1 [Fast switching] + ENTER.
 Selectanitemwith◄►+ENTER.
• [Internal rate]:Theoutputframerateis60Hzor75Hzdependingoftheselectedoutputformat.Ahigherframe
frequency gives a better visual aspect when displaying static pictures.
• [Follow # x]: TheoutputframerateisidenticaltotheselectedinputFrameRate:50Hziftheinputvideo
standardisPALorSECAMand59.94HziftheinputvideostandardisNTSC.Thisfunction
allows improving the motion pictures.
1-2 [Seamless] + ENTER.
 Selectthecomputerinputusedasreferencewith◄►+ENTER.
• [Seamless #1] : The device is in Seamless mode. The output format & rate are the same as computer #1.
• [Seamless #8] : The device is in Seamless mode. The output format & rate are the same as computer #8.
2►[INPUT] + ENTER.
2-1 [Auto settings] + ENTER.
This function detects automatically the input type of each source connected to the inputs.
2-2 [Input status] + ENTER.
Indicates the status of the selected input.
2-3 [Input type] + ENTER.
①Selectaninputwith◄►+ENTER.
②Selecttheinputsignaltypewith◄►+ENTERbetween:
• [SDTV Composite] • [SDTV RGB SOG]
• [SDTV S.VIDEO] • [SDTV RGBS ana.]
• [SDTV YUV] • [Computer SOG]
• [SDTV RGBS TTL] • [Computer HV/C]
• [Computer DVI]
• [HDTV]:HDTVinputformat(720p,1035iand1080i).
• [Audio only] : Select this function if you only want to connect an audio source (no video signal needed).
③ Then for [SDTV Composite] and [SDTV S.VIDEO],selectthevideostandardwith◄►+ENTERbetween:
• [NTSC / PAL / SECAM] : automatic NTSC, PAL, and SECAM standard detection.
• [NTSC] : NTSC standard detection only. • [PAL] : PAL standard detection only.
• [NTSC4.4360Hz]:NTSC4.4360Hzdetection. •[PAL4.4360Hz]:PAL4.4360Hzdetection.
• [SECAM] : SECAM standard detection only. • [B&W50/60Hz] : Black and White detection.
2-4 [used input] + ENTER.
 Selectaninputandthenselectanitem◄►+ENTERbetween:
• [used] : A signal is connected to the input.
• [unused] : No signal is connected to the input. The input is unused.
2-5 [H sync load] + ENTER.
 SelectforeachinputtheloadoftheHSync.with◄►+ENTER.
2-6 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2-7 [VIS] + ENTER.
 Thisfunctionallowsdeningthesourceswhicharesynchronizedtogether(externalgenlock).Thesynchroni-
zed sources can be seamlessly switched between themselves during an effect (into a PIP for example). This
switching mode is called VIS (Vertical Interval Switching).
PAGE 27
