FRONT PANEL MENU DISPLAY DESCRIPTION

5-1. INTRODUCTION

5-3. INTRODUCTION

5-2. CONTROL BUTTONS

The front panel display menu presents 2 modes : STATUS MODE and CONTROL MODE.

• The STATUS MODE indicates the input and output status of the device.

• The CONTROL MODE allows selecting and adjusting the parameters of the device.

The front panel display is controlled by 2 buttons and 1 knob :

◄►knob:  •InCONTROLMODE,turnthisknobtoscrollthruthedifferentmenus.

EXIT / MENU button : • In STATUS MODE, press this button to enter CONTROL MODE.

• In CONTROL MODE, press this button to :

- return to the previous menu without saving the selection.

- return to STATUS MODE (press several times).

ENTER button : • From STATUS MODE, press this button to enter CONTROL MODE.

• From CONTROL MODE, press this button to confirm a selected item.

WhenswitchingON,thefrontpaneldisplayshowstheproduct’snameandrmwareversionasfollows:

OXE831

Version 242

MAIN : 1

XGA60.1K/75Hz

PREVIEW : 2

YUV15.7K/50Hz

Output:1024x768

Seamless #1 75Hz

DEVICE STATUS

MAIN STATUS

PREVIEW STATUS

OUTPUT STATUS

1/ Device reference

2/ Device version

3/ MAIN output : selected input number

4/ Format, line & frame frequency to the selected input

5/ PREVIEW output : pre-selected input number

6/ Format, line & frame frequency of the pre-selected input

7/ Output format

8/ Switching mode & output frame rate
