Manual

OPERATING MODE
The device can be used in two different switching modes :
• The SEAMLESS MODE,allowsswitchingseamlessly,fadingandtitlingbetweenthe“reference”COMPUTER
inputandtheotherinputs.Otherinputsarescaledtothesameformatasthe“reference”COMPUTERformat.
NOTE : Input #1 and #8 can be used as the reference capter input.
NOTE :The“reference”Computerisnotscaled.
• The FAST SWITCHING MODE allows selecting an output format corresponding to your application. All video
inputs are scaled to the selected format. The switching between two inputs will go through a fade colored tran-
sition.Theoutputratecanbeselectedbetween60Hz,75Hzorcanbesynchronizedtooneofthevideoinput
framerateinordertoimprovethemotionpicture.Inthiscase,theoutputframeratewillbe50Hziftheinputis
inPALorSECAM,and59.94HziftheinputisinNTSC.
3-1. SETTINGS
1) We recommend resetting the device to its default values, with the LCD menu (CONTROL > Default value > yes)
before proceeding.
2) Select a switching mode with the LCD menu (SWITCHING > fast switching or seamless). Please see the
Switching mode table below.
3) Select the Auto settings function with the LCD menu (INPUT > Auto settings). This function will detect automa-
tically the source type connected to the inputs of the device. Sometimes, the auto setting may not detect the
source type : in this case select manually the source type with the LCD menu (INPUT > Input type).
4) If you have selected the fast switching mode : select one of the output formats with the LCD menu (OUTPUT >
output format).
NOTE : For xed pixels display devices (DMD, LCD, PLASMA…), always select the output format corres-
ponding to the native resolution of your device. Thus, the display device will not have to scale the image
and the result will be better.
NOTE : In SEAMLESS mode, the output format is the same as the “reference” computer format.
3-2. SWITCHING OPERATIONS
• The device allows 4 different switching effects : CUT*, FADE*, FADE COLOR and CLEAN CUT. The CUT effect allows
switching seamlessly between 2 sources. The FADE effect allows fading out the displayed source while another source
is fading in. The FADE COLOR effect allows switching between 2 sources with a fading through the color of you choice.
The CLEAN CUT allows a clean switching thanks to a fast freeze of the displayed source.
• PIP* = Picture in Picture is also available effect.
• OXE831 also enables you to key text onto the displayed image (TITLE* effect).
PAGE 17
SWITCHING MODE TABLE
SWITCHING MODE
FAST SWITCHING
SEAMLESS
internal rate “input # x”
TRANSITION
All switching through a
fade color, a fade frame or
a clean cut.
All switching through a fade
color, a fade frame or a clean
cut.
• Seamless or fade transition
betweenthe“reference”com-
puter and all other inputs.
• Between "non reference"
inputs switching through a
fade color, a fade frame or a
clean cut.
OUTPUT FRAME RATE Generated by the device
(60Hzor75Hz).
Synchronized on the selected
inputframerate(50HzifPAL
or SECAM and 59.94 Hz if
NTSC).
Synchronized on the “refe-
rence” Computer frame rate
(input #1 or input #8).
!
*
The CUT, FADE, PIP and TITLE effects are active in SEAMLESS mode and only between the reference
computer input and the other inputs.
