ADV7174/ADV7179
Rev. B | Page 9 of 52
ABSOLUTE MAXIMUM RATINGS
Table 5.
Parameter Rating
V
AA
to GND 4 V
Voltage on Any Digital Input Pin GND – 0.5 V to V
AA
+ 0.5 V
Storage Temperature (T
S
) −65°C to +150°C
Junction Temperature (T
J
) 150°C
Lead Temperature
Soldering, 10 sec
260°C
Analog Outputs to GND
1
GND – 0.5 V to V
AA
θ
JA
2
30°C/W
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those listed in the operational sections
of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability
__________________________________________________
1
Analog output short circuit to any power supply or common can be of an indefinite duration.
2
With the exposed metal paddle on the underside of LFCSP soldered to GND on the PCB.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
