ADV7174/ADV7179

Rev. B | Page 51 of 52

Table 26. PAL-60 (F

= 4.43361875 MHz)

Address Description Data

00H Mode Register 0 04H

01H Mode Register 1 10H

02H Mode Register 2 00H

03H Mode Register 3 00H

04H Mode Register 4 00H

07H Timing Register 0 00H

08H Timing Register 1 00H

09H Subcarrier Frequency Register 0 CBH

0AH Subcarrier Frequency Register 1 8AH

0BH Subcarrier Frequency Register 2 09H

0CH Subcarrier Frequency Register 3 2AH

0DH Subcarrier Phase Register 00H

0EH Closed Captioning Ext Register 0 00H

0FH Closed Captioning Ext Register 1 00H

10H Closed Captioning Register 0 00H

11H Closed Captioning Register 1 00H

12H Pedestal Control Register 0 00H

13H Pedestal Control Register 1 00H

14H Pedestal Control Register 2 00H

15H Pedestal Control Register 3 00H

16H CGMS_WSS Register 0 00H

17H CGMS_WSS Register 1 00H

18H CGMS_WSS Register 2 00H

19H Teletext Request Control Register 00H

Table 27. NTSC (F

= 3.5795454 MHz)
